ICCA1 RF Module Test Setup Photos - FCC ID FHO-ICC-A-1

FCC ID FHO-ICC-A-1

Test Setup Photos

RF Module

by IKEA of Sweden AB

Document preview loads when visible.

Document Details

FCC IDFHO-ICC-A-1
Document ID3432947
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantIKEA of Sweden AB
Equipment ClassRF Module
Product CodeICCA1
Application IDu6nTbB4hvPfc6eCR+t9sfQ==
Application PurposeOriginal Equipment
Application Date2017-06-21
Frequency Range2405-2480 MHz
FRN0021625967
Test FirmIntertek Semko AB
Certified ByIvan Susak Team Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/18/2017
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2017-06-21
Available2017-12-18
Created2017-04-24
Modified2017-04-24
Pages3
File TypeAdobe Acrobat PDF
File Size746536
File SHA-25683bfcb7d3492f663ec97ed5cd54046e28d84a19ed1f464f1cdbdc817b4c92609
FCC.gov SourcesFCC.gov 3432947
