FCC ID FIHAI1422E
Location Monitoring Services Transmitter
by TransCore
Grantee Code: FIH Product Code: AI1422E
Latest application date: 2017-10-03
Device Images
FCC ID Device Details
| FCC ID | FIHAI1422E |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | FIH |
| Product Code | AI1422E |
| Applicant Business | TransCore 🇺🇸 |
| Related Domains |  transcore.com |
| Equipment Class | Location Monitoring Services Transmitter |
| Test Firm | Rogers Labs, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 902.25-903.75 MHz | Class II permissive change or modification of presently authorized equipment | 2017-10-03 |
| 902.25-903.75 MHz | Original Equipment | 2016-09-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-10-03 | PDF 3.2 MB |
| Users Manual | Users Manual | 2016-09-15 | PDF 1.7 MB |
| Internal Photos | Internal Photos | 2017-10-03 | PDF 436.2 KB |
| Internal Photos | Internal Photos | 2016-09-15 | PDF 681.2 KB |
| External Photos | External Photos | 2016-09-15 | PDF 420.8 KB |
| Label Sample | ID Label/Location Info | 2017-10-03 | PDF 352 KB |
| Label Sample | ID Label/Location Info | 2016-09-15 | PDF 153.3 KB |
| Test Setup Photo | Test Setup Photos | 2017-10-03 | PDF 1.1 MB |
| Test Setup Photos | Test Setup Photos | 2016-09-15 | PDF 1.1 MB |
| Test Report | Test Report | 2017-10-03 | PDF 1.5 MB |
| Test Report | Test Report | 2016-09-15 | PDF 1.3 MB |
| Authorization Letter | Cover Letter(s) | 2017-10-03 | PDF 43.5 KB |
| C2PC Letter | Cover Letter(s) | 2017-10-03 | PDF 142.4 KB |
| Agent Authorization | Cover Letter(s) | 2016-09-15 | PDF 90.6 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-09-15 | PDF 281.4 KB |
| RF Exposure | RF Exposure Info | 2017-10-03 | PDF 257.1 KB |
| RF Exposure | RF Exposure Info | 2016-09-15 | PDF 116.3 KB |
| Tune Up Procedures | Parts List/Tune Up Info | 2016-09-15 | PDF 77.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 86.1 KB | |
| Schematics Metadata only | Schematics | PDF 1.4 MB | |
| Operational Description Metadata only | Operational Description | PDF 137.8 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 112.1 KB |
Application Information
| Application ID | jWndgYGsE3oIWKDV9njARg== |
|---|---|
| Final Action Date | 2017-10-03 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0006083745 |
| Model | AI1422E |
| Frequency Range | 902.25-903.75 MHz |
| Equipment Class | LMS - Part 90 Location & Monitoring Transmitter |
| Device Description | Location Monitoring Services Transmitter |
| Responsible Party | Dale Scott, VP of Engineering and Manufacturing, dale.scott@transcore.com , 505 856-8178 |
| Test Firm | Scot Rogers, Rogers Labs, Inc., rogers@pixius.net  , 913-837-3214 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. This device must be professionally installed. The peak radiated output power, including antenna gain and cable loss, must not exceed 30 W ERP. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 80 cm from user, 36cm from occupational operator and must not be co-located or operating in conjunction with any other antenna or transmitter. The maximum antenna height above ground for non-multilateration LMS systems is 15 meters. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| jWndgYGsE3oIWKDV9njARg== | 2017-10-03 | Class II permissive change or modification of presently authorized equipment |
| PhbFicoGuyqWeqcoqz9faw== | 2016-09-15 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules |
|---|---|---|---|---|
| 902.25-903.75 MHz | 2 | 2.5ppm | 0H00N0N | 90.353 |
| 902.25-903.75 MHz | 2 | 2.5ppm | 460KN0N | 90.353 |
| 910-921.5 MHz | 2 | 2.5ppm | 0H00N0N | 90.353 |
| 910-921.5 MHz | 2 | 2.5ppm | 460KN0N | 90.353 |
| 911.75-919.75 MHz | 2 | 2.5ppm | 678KL1D | 90.353 |
| 911.75-919.75 MHz | 2 | 2.5ppm | 703KL1D | 90.353 |
| 911.75-919.75 MHz | 2 | 2.5ppm | 705KL1D | 90.353 |
| 911.75-919.75 MHz | 2 | 2.5ppm | 485KL1D | 90.353 |
Grants
TCB Grant - Application PhbFicoGuyqWeqcoqz9faw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/15/2016 Application Dated: 09/14/2016 |
| TransCore |
| Amtech Technology Center |
| 8600 Jefferson Street, NE |
| Albuquerque, NM 87113 |
| Attention: Dale Scott , VP of Engineering and Manufacturing |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | FIHAI1422E |
| Name of Grantee: | TransCore |
| Equipment Class: | Part 90 Location & Monitoring Transmitter |
| Notes: | Location Monitoring Services Transmitter |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 90.353 | 902.25 - 903.75 | 2.0 | 2.5 PM | 460KN0N | |
| 90.353 | 910.0 - 921.5 | 2.0 | 2.5 PM | 460KN0N |
| Power listed is conducted. This device must be professionally installed. The peak radiated output power, including antenna gain and cable loss, must not exceed 30 W ERP. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 80 cm from user, 36cm from occupational operator and must not be co-located or operating in conjunction with any other antenna or transmitter. The maximum antenna height above ground for non-multilateration LMS systems is 15 meters. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application PhbFicoGuyqWeqcoqz9faw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TransCore Amtech Technology Center 8600 Jefferson Street, NE Albuquerque, NM 87113 United States |
Date of Grant: 09/15/2016 Application Dated: 09/14/2016 |
| Attention: Dale Scott , VP of Engineering and Manufacturing |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | FIHAI1422E |
| Name of Grantee: | TransCore |
| Equipment Class: | Part 90 Location & Monitoring Transmitter |
| Notes: | Location Monitoring Services Transmitter |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 90.353 | 902.25 - 903.75 | 2.0 | 2.5 PM | 460KN0N | |
| 90.353 | 910.0 - 921.5 | 2.0 | 2.5 PM | 460KN0N |
| Power listed is conducted. This device must be professionally installed. The peak radiated output power, including antenna gain and cable loss, must not exceed 30 W ERP. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 80 cm from user, 36cm from occupational operator and must not be co-located or operating in conjunction with any other antenna or transmitter. The maximum antenna height above ground for non-multilateration LMS systems is 15 meters. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/03/2017 Application Dated: 10/03/2017 |
| TransCore |
| Amtech Technology Center |
| 8600 Jefferson Street, NE |
| Albuquerque, NM 87113 |
| Attention: Dale Scott , VP of Engineering and Manufacturing |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | FIHAI1422E |
| Name of Grantee: | TransCore |
| Equipment Class: | Part 90 Location & Monitoring Transmitter |
| Notes: | Location Monitoring Services Transmitter |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 90.353 | 902.25 - 903.75 | 2.0 | 2.5 PM | 0H00N0N | |
| 90.353 | 910.0 - 921.5 | 2.0 | 2.5 PM | 0H00N0N | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 678KL1D | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 703KL1D | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 705KL1D | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 485KL1D |
| Power listed is conducted. This device must be professionally installed. The peak radiated output power, including antenna gain and cable loss, must not exceed 30 W ERP. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 80 cm from user, 36cm from occupational operator and must not be co-located or operating in conjunction with any other antenna or transmitter. The maximum antenna height above ground for non-multilateration LMS systems is 15 meters. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application jWndgYGsE3oIWKDV9njARg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TransCore Amtech Technology Center 8600 Jefferson Street, NE Albuquerque, NM 87113 United States |
Date of Grant: 10/03/2017 Application Dated: 10/03/2017 |
| Attention: Dale Scott , VP of Engineering and Manufacturing |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | FIHAI1422E |
| Name of Grantee: | TransCore |
| Equipment Class: | Part 90 Location & Monitoring Transmitter |
| Notes: | Location Monitoring Services Transmitter |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 90.353 | 902.25 - 903.75 | 2.0 | 2.5 PM | 0H00N0N | |
| 90.353 | 910.0 - 921.5 | 2.0 | 2.5 PM | 0H00N0N | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 678KL1D | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 703KL1D | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 705KL1D | |
| 90.353 | 911.75 - 919.75 | 2.0 | 2.5 PM | 485KL1D |
| Power listed is conducted. This device must be professionally installed. The peak radiated output power, including antenna gain and cable loss, must not exceed 30 W ERP. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 80 cm from user, 36cm from occupational operator and must not be co-located or operating in conjunction with any other antenna or transmitter. The maximum antenna height above ground for non-multilateration LMS systems is 15 meters. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| Mail To: |
