H302P Wireless Alarm System, PIR Detector... - FCC ID FU5H302P

FCC ID FU5H302P

Block diagram

Wireless Alarm System, PIR Detector

by Everspring Industry Co Ltd

Document preview loads when visible.

Document Details

FCC IDFU5H302P
Document ID407438
Document TypeBlock Diagram
DescriptionBlock diagram
ApplicantEverspring Industry Co Ltd
Equipment ClassWireless Alarm System, PIR Detector
Product CodeH302P
Application IDbfjref4JMtkOQEJw0gsR8w==
Application PurposeOriginal Equipment
Application Date2004-03-19
Frequency Range433.92 MHz
FRN0006923148
Test FirmDEKRA Testing and Certification Co., Ltd.
Certified ByGene Chang President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-03-23
Available2004-03-19
Created2004-03-10
Modified2004-03-10
Pages1
File TypeAdobe Acrobat PDF
File Size90938
File SHA-2560fa02a05576b34666c9cf6866d9005f970ec0370e571ccb87c8d71f075dc0635
PDF Metadata ProducerAcrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows
FCC.gov SourcesFCC.gov 407438
