CTD201 2.4 GHz Cordless Telephone Teardown... - FCC ID GAFCT-D201

FCC ID GAFCT-D201

internal photos

2.4 GHz Cordless Telephone

by Columbia Telecommunications Group Inc

Document preview loads when visible.

Document Details

FCC IDGAFCT-D201
Document ID326072
Document TypeInternal Photos
Descriptioninternal photos
Document Title560AUT3 internals
ApplicantColumbia Telecommunications Group Inc
Equipment Class2.4 GHz Cordless Telephone
Product CodeCTD201
Application ID2ql3Qp+ivBqjbIUvUphp4w==
Application PurposeOriginal Equipment
Application Date2003-05-15
Frequency Range2404.8-2478.6 MHz
FRN0004265807
Test FirmTimco Engineering, Inc.
Certified ByDavid Giladi President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-05-16
Available2003-05-15
Created2003-05-09
Modified2003-05-16
Pages4
File TypeAdobe Acrobat PDF
File Size628037
File SHA-256ebb5abb11908922f1b7aa430e57a05de8dc8ac1b06b4e644ad68dcdcf085e6f6
PDF Metadata ProducerAcrobat PDFWriter 4.05 for Windows
FCC.gov SourcesFCC.gov 326072
