TP00064B Tablet Computer Test Setup Photos - FCC ID GKR-TP00064B

FCC ID GKR-TP00064B

Test Setup Photos BLE

Tablet Computer

by Compal Electronics Inc

Document preview loads when visible.

Document Details

FCC IDGKR-TP00064B
Document ID2617418
Document TypeTest Setup Photos
DescriptionTest Setup Photos BLE
ApplicantCompal Electronics Inc
Equipment ClassTablet Computer
Product CodeTP00064B
Application IDun4V92aJ4P6uV3NujIEsJg==
Application PurposeOriginal Equipment
Application Date2015-05-18
Frequency Range2402-2480 MHz
FRN0020269494
Test FirmCompliance Certification Services Inc.
Certified ByJoyce Ting
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date11/14/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-05-18
Available2015-11-14
Created2015-04-28
Modified2015-04-28
Pages2
File TypeAdobe Acrobat PDF
File Size397512
File SHA-2561b74a10438428e8564f6d6ea474f55b0ff2dd95fec9d4a1f1c9f6919fc883cc6
PDF Metadata AuthorWen Kuei Lo
PDF Metadata ProducerWen Kuei Lo Microsoft® Word 2010
FCC.gov SourcesFCC.gov 2617418
