60153R WIRELESS REMOTE CONTROL RECEIVER Block... - FCC ID GLE60153R

FCC ID GLE60153R

Block Diagram

WIRELESS REMOTE CONTROL RECEIVER

by Suncon Toys Industry Ltd

Document preview loads when visible.

Document Details

FCC IDGLE60153R
Document ID747643
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleBLOCK DIAGRAM
ApplicantSuncon Toys Industry Ltd
Equipment ClassWIRELESS REMOTE CONTROL RECEIVER
Product Code60153R
Application IDL8QRnNFA/j65o7SEvMhxAA==
Application PurposeOriginal Equipment
Application Date2007-01-16
Frequency Range49.86 MHz
FRN0005857198
Test FirmTimco Engineering, Inc.
Certified ByGarry Yeung
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2007-01-16
Available2007-01-16
Created2007-01-16
Modified2007-01-16
Pages1
File TypeAdobe Acrobat PDF
File Size11319
File SHA-256a4a4aace409d7e7c81d3d30c6cb42ddb89a52fc7019610496dc66f661fc01a2a
PDF Metadata AuthorAnyuser
PDF Metadata CreatorAcrobat PDFMaker 7.0.7 for Word
PDF Metadata ProducerAcrobat Distiller 7.0.5 (Windows)
FCC.gov SourcesFCC.gov 747643
