EMC Test Report
TRWTX-1702216TX
Issued: January 28, 2018
regarding
USA: CFR Title 47, Part 15.231 (Emissions)
Canada:
ISED RSS-210v9
(Emissions)
for
336600
Category: RKE Transmitter
Judgements:
FCC 15.231, ISED RSS-210v9 Compliant
Tested: January 19, 2018
NVLAP LAB CODE 200129-0
Prepared for:
TRW Automotive
24175 Research Drive, Farmington Hills Michigan 48335-2642 USA
Phone: +1 (248) 699-4487
Fax: +1 (248) 699-4102
Contact: Mark Baker
mark.baker@zf.com
Reviewed by:
Data Recorded by:
Gordon Helm, EMC-002401-NE
Prepared by:
Dave Miller, EMC-003027-NE
Date of Issue:
January 28, 2018
Dr. Joseph Brunett, EMC-002790-NE
A copy of this report will remain on file until January 2028.
Page 1 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Revision History
Rev. No.
Date
Details
Revised By
r0
r1
January 28, 2018
February 1, 2018
Initial Release.
Data Table Corrections.
J. Brunett
J. Brunett
Contents
Revision History
Table of Contents
1 Test Report Scope and Limitations
1.1 Laboratory Authorization . . . . .
1.2 Report Retention . . . . . . . . . .
1.3 Subcontracted Testing . . . . . . .
1.4 Test Data . . . . . . . . . . . . . .
1.5 Limitation of Results . . . . . . . .
1.6 Copyright . . . . . . . . . . . . . .
1.7 Endorsements . . . . . . . . . . . .
1.8 Test Location . . . . . . . . . . . .
1.9 Traceability and Equipment Used .
2 Test Specifications and Procedures
2.1 Test Specification and General Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Configuration and Identification of the Equipment Under Test
3.1 Description and Declarations . . . . . . . . . . . . . . . . . . . . .
3.1.1 EUT Configuration . . . . . . . . . . . . . . . . . . . . . . .
3.1.2 Modes of Operation . . . . . . . . . . . . . . . . . . . . . .
3.1.3 Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.4 Test Samples . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.5 Functional Exerciser . . . . . . . . . . . . . . . . . . . . . .
3.1.6 Modifications Made . . . . . . . . . . . . . . . . . . . . . .
3.1.7 Production Intent . . . . . . . . . . . . . . . . . . . . . . .
3.1.8 Declared Exemptions and Additional Product Notes . . . .
4 Emissions
4.1 General Test Procedures . . . . . . . . . . . . . . . . . .
4.1.1 Radiated Test Setup and Procedures . . . . . . .
4.1.2 Conducted Emissions Test Setup and Procedures
4.1.3 Power Supply Variation . . . . . . . . . . . . . .
4.2 Intentional Emissions . . . . . . . . . . . . . . . . . . . .
4.2.1 Fundamental Emission Pulsed Operation . . . .
4.2.2 Fundamental Emission Bandwidth . . . . . . . .
4.2.3 Fundamental Emission Field Strength . . . . . .
4.3 Unintentional Emissions . . . . . . . . . . . . . . . . . .
4.3.1 Transmit Chain Spurious Emissions . . . . . . .
4.3.2 Radiated Digital Spurious . . . . . . . . . . . . .
11
11
12
12
14
15
16
16
17
5 Measurement Uncertainty and Accreditation Documents
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
18
Page 2 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
List of Tables
Test Site List. . . . . . . . . . . . . . . . .
Equipment List. . . . . . . . . . . . . . .
EUT Declarations. . . . . . . . . . . . . .
Fundamental Emission Pulsed Operation.
Fundamental Emission Bandwidth. . . .
Fundamental Emission Field Strength. .
Transmit Chain Spurious Emissions. . . .
Measurement Uncertainty. . . . . . . . . .
12
14
15
16
18
Photos of EUT. . . . . . . . . . . . . . . . . .
EUT Test Configuration Diagram. . . . . . . .
Radiated Emissions Diagram of the EUT. . . .
Radiated Emissions Test Setup Photograph(s).
Fundamental Emission Pulsed Operation. . . .
Fundamental Emission Bandwidth. . . . . . .
Accreditation Documents . . . . . . . . . . . .
10
13
14
18
List of Figures
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 3 of 18
Date: January 28, 2018
1.1
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Test Report Scope and Limitations
Laboratory Authorization
Test Facility description and attenuation characteristics are on file with the FCC Laboratory, Columbia, Maryland
(FCC Reg. No: 90413) and with ISED Canada, Ottawa, ON (File Ref. No: IC3161). Amber Helm Development
L.C. holds accreditation under NVLAP Lab Code 200129-0 and includes within its scope CFR Title 47 Part 15
Subparts B and C.
1.2
Report Retention
For equipment verified to comply with the regulations herein, the manufacturer is obliged to retain this report with
the product records for the life of the product, and no less than ten years. A copy of this Report will remain on file
with this laboratory until January 2028.
1.3
Subcontracted Testing
This report does not contain data produced under subcontract.
1.4
Test Data
This test report contains data included within the laboratories scope of accreditation.
1.5
Limitation of Results
The test results contained in this report relate only to the item(s) tested. Any electrical or mechanical modification
made to the test item subsequent to the test date shall invalidate the data presented in this report. Any electrical
or mechanical modification made to the test item subsequent to this test date shall require reevaluation.
1.6
Copyright
This report shall not be reproduced, except in full, without the written approval of Amber Helm Development L.C..
1.7
Endorsements
This report shall not be used to claim product endorsement by any accrediting, regulatory, or governmental agency.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 4 of 18
Date: January 28, 2018
1.8
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Test Location
The EUT was fully tested by Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA. Table 1 lists all sites employed herein. Specific test sites utilized are also listed in the test results
sections of this report.
Table 1: Test Site List.
1.9
Description
Location
Quality Num.
OATS (3m & 10m)
92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
OATSA
Traceability and Equipment Used
Pertinent test equipment used for measurements at this facility is listed in Table 2. The quality system employed at
Amber Helm Development L.C. has been established to ensure all equipment has a clearly identifiable classification,
calibration expiry date, and that all calibrations are traceable to the SI through NIST, other recognized national
laboratories, accepted fundamental or natural physical constants, ratio type of calibration, or by comparison to
consensus standards.
Table 2: Equipment List.
Description
Manufacturer/Model
SN
Quality Num.
Last Cal By / Date Due
BiconiLog Antenna
(3m) RG8 Coax
EMCO / 3142
CS-3227 / CS-3227
BILO3142
CS3227
Lib.Labs / May-2018
AHD / Mar-2018
EMI Receiver
HP / 85460A/85462A
HP8546A
Techmaster / Apr-2018
Spectrum Analyzer
(3m) LMR-400 Coax
(LCI) DS Coax
(10-m) Amelco Coax
Double Ridged Horn
Rohde & Schwarz / FSV30
AHD / LMR400
AHD / RG58/U
AHD / RG213U
EMCO / 3115
1169
C060914
3704A00422,
3807A00465
101660
C090804
920809
9903-10ab
2788
RSFSV30001
LMR400
RG58U
RG213U
RH3115
RS / May-2018
AHD / Mar-2018
AHD / Jul-2018
AHD / Mar-2018
Lib.Labs. / July-2018
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 5 of 18
Date: January 28, 2018
2.1
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Test Specifications and Procedures
Test Specification and General Procedures
The ultimate goal of TRW Automotive is to demonstrate that the Equipment Under Test (EUT) complies with the
Rules and/or Directives below. Detailed in this report are the results of testing the TRW Automotive 336600 for
compliance to:
Country/Region
Rules or Directive
Referenced Section(s)
United States
Canada
Code of Federal Regulations
ISED Canada
CFR Title 47, Part 15.231
ISED RSS-210v9
It has been determined that the equipment under test is subject to the rules and directives above at the date of
this testing. In conjunction with these rules and directives, the following specifications and procedures are followed
herein to demonstrate compliance (in whole or in part) with these regulations.
ANSI C63.4:2014
”Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz”
ANSI C63.10:2013 (USA)
”American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices”
TP0102RA
”AHD Internal Document TP0102 - Radiated Emissions Test Procedure”
ISED Canada
”The Measurement of Occupied Bandwidth”
ICES-003; Issue 6 (2016)
“Information Technology Equipment (ITE) Limits and methods of measuremen”
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 6 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Configuration and Identification of the Equipment Under Test
3.1
Description and Declarations
The equipment under test is a remote keyless entry transmitter. The EUT is approximately 4 x 2.5 x 1.5 cm
(approx) in dimension, and is depicted in Figure 1. It is powered by 3 VDC lithium coin cell. In use, this device is
hand held. Table 3 outlines provider declared EUT specifications.
Figure 1: Photos of EUT.
Table 3: EUT Declarations.
General Declarations
Equipment Type:
Nominal Supply:
Frequency Range:
Antenna Type:
Number of Channels:
Alignment Range:
RKE Transmitter
3 VDC
312.1 and 314.35 MHz
Integral
Not Declared
Country of Origin:
Oper. Temp Range:
Antenna Dimension:
Antenna Gain:
Channel Spacing:
Type of Modulation:
Not Declared
Not Declared
Not Declared
Not Declared
Not Declared
FSK
United States
FCC ID Number:
GQ4-73T
Classification:
DSC
1470A-54T
Classification:
Remote Control Device, Vehicular Device
Canada
IC Number:
3.1.1
EUT Configuration
The EUT is configured for testing as depicted in Figure 2.
3.1.2
Modes of Operation
The EUT employs only a single mode of operation, as a manually activated transmitter. Upon single button press,
the EUT will transmit one 716 ms FSK frame on one of two RF channels. Only a single channel is employed with a
single button press, and the EUT switches channels between presses.
3.1.3
Variants
There is only a single variant of the EUT, as tested.
3.1.4
Test Samples
Two normal operating samples were provided for testing.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 7 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
TRW RKE Transmitter
Model: 336600
FCC ID: GQ4-73T
IC: 1470A-54T
Figure 2: EUT Test Configuration Diagram.
3.1.5
Functional Exerciser
Normal operating EUT functionality was verified by observation of transmitted signal.
3.1.6
Modifications Made
There were no modifications made to the EUT by this laboratory.
3.1.7
Production Intent
The EUT appears to be a production ready sample.
3.1.8
Declared Exemptions and Additional Product Notes
None.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 8 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Emissions
4.1
4.1.1
General Test Procedures
Radiated Test Setup and Procedures
Radiated electromagnetic emissions from the EUT are first pre-scanned in our screen room. Spectrum and modulation
characteristics of all emissions are recorded. Instrumentation, including spectrum analyzers and other test equipment
as detailed in Section 1.8 are employed. After pre-scan, emission measurements are made on the test site of record.
If the EUT connects to auxiliary equipment and is table or floor standing, the configurations prescribed in relevant
test standards are followed. Alternatively, a layout closest to normal use (as declared by the provider) is employed
if the resulting emissions appear to be worst-case in such a configuration. See Figure 3. All intentionally radiating
elements that are not fixed-mounted in use are placed on the test table lying flat, on their side, and on their end
(3-axes) and the resulting worst case emissions are recorded. If the EUT is fixed-mounted in use, measurements are
made with the device oriented in the manner consistent with installation and then emissions are recorded. If the
EUT exhibits spurious emissions due to internal receiver circuitry, such emissions are measured with an appropriate
carrier signal applied.
Long Interface Cables
EUT Power
(to AUX)
Equipment Under Test
(EUT)
Long Interface Cables
AUX Power
(to EUT)
Short Interface Cables
Auxiliary
Equipment
(AUX)
Radiated Emissions Table
Figure 3: Radiated Emissions Diagram of the EUT.
For devices with intentional emissions below 30 MHz, a shielded loop antenna and/or E-field and H-Field broadband probes are used depending on the regulations. Shielded loops are placed at a 1 meter receive height at the desired
measurement distance. For exposure in this band, the broadband probes employed are 10cm diameter single-axis
shielded transducers and measurements are repeated and summed over three axes.
Emissions between 30 MHz and 1 GHz are measured using calibrated broadband antennas. For both horizontal
and vertical polarizations, the test antenna is raised and lowered from 1 to 4 m in height until a maximum emission
level is detected. The EUT is then rotated through 360o in azimuth until the highest emission is detected. The test
antenna is then raised and lowered one last time from 1 to 4 m and the worst case value is recorded. Emissions
above 1 GHz are characterized using standard gain or broadband ridge-horn antennas on our OATS with a 4 × 5
m rectangle of ECCOSORB absorber covering the OATS ground screen and a 1.5m table height. Care is taken to
ensure that test receiver resolution and video bandwidths meet the regulatory requirements, and that the emission
bandwidth of the EUT is not reduced. Photographs of the test setup employed are depicted in Figure 4.
Where regulations allow for direct measurement of field strength, power values (dBm) measured on the test
receiver / analyzer are converted to dBµV/m at the regulatory distance, using
Edist = 107 + PR + KA − KG + KE − CF
where PR is the power recorded on spectrum analyzer, in dBm, KA is the test antenna factor in dB/m, KG is the
combined pre-amplifier gain and cable loss in dB, KE is duty correction factor (when applicable) in dB, and CF is
a distance conversion (employed only if limits are specified at alternate distance) in dB. This field strength value is
then compared with the regulatory limit. If effective isotropic radiated power (EIRP) is computed, it is computed as
EIRP (dBm) = E3m (dBµV /m) − 95.2.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 9 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
When presenting data at each frequency, the highest measured emission under all possible EUT orientations (3-axes)
is reported.
Figure 4: Radiated Emissions Test Setup Photograph(s).
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 10 of 18
Date: January 28, 2018
4.1.2
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Conducted Emissions Test Setup and Procedures
Battery Power Conducted Spurious The EUT is not subject to measurement of power line conducted emissions
as it is powered solely by its internal battery.
4.1.3
Power Supply Variation
Tests at extreme supply voltages are made if required by the the procedures specified in the test standard, and results
of this testing are detailed in this report.
In the case the EUT is designed for operation from a battery power source, the extreme test voltages are evaluated
over the range specified in the test standard; no less than ±10% of the nominal battery voltage declared by the
manufacturer. For all battery operated equipment, worst case intentional and spurious emissions are re-checked
employing a new (fully charged) battery.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 11 of 18
Date: January 28, 2018
4.2
4.2.1
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Intentional Emissions
Fundamental Emission Pulsed Operation
Test Setup & Procedure The test equipment and facilities were setup in accordance with the standards and
procedures listed in Section 2.1. Environmental conditions were set at the appropriate temperature and thermal
balance was checked with a thermocouple based probe. Duty cycle is reported for all relevant modes of operation.
The test equipment employed includes RSFSV30001, BILOG3142.
Measurement Results The details and results of testing the EUT are summarized in Table 4. Plots showing the
measurements made to obtain these values are provided in Figure 5.
Table 4: Fundamental Emission Pulsed Operation.
Detector
Pk
Span
IF Bandwidth
1 MHz
Test Date:
Test Engineer:
EUT:
EUT Mode:
Meas. Distance:
Video Bandwidth
3 MHz
20-Jan-18
Joseph Brunett
TRW Toy Tx
Modulated
10 cm
FCC/IC
Overall Transmission
Internal Frame Characteristics
Frequency
EUT Test Mode*
Min.
Repetition
Rate (sec)
Max.
No. of
Frames
Total
Transmission
Length (sec)
Max. Frame
Length (ms)
Min. Frame
Period (ms)
312.1 MHz
Manual Activation
single
0.716
716.000
314.35 MHz
Manual Activation
single
0.716
716.000
Computed Duty
Cycle
Frame Encoding
(%)
(dB)
The EUT transmits a single 716 ms long
frame of FSK encoded data.
100.0
0.0
The EUT transmits a single 716 ms long
frame of FSK encoded data.
100.0
0.0
Example Calculation: Worst Case 315 FSK Duty (%) = 100ms / 100 ms x 100 = 100 %
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 12 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Figure 5: Fundamental Emission Pulsed Operation.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 13 of 18
Date: January 28, 2018
4.2.2
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Fundamental Emission Bandwidth
Test Setup & Procedure The test equipment and facilities were setup in accordance with the standards and
procedures listed in Section 2.1. Environmental conditions were set at the appropriate temperature and thermal
balance was checked with a thermocouple based probe. Emission bandwidth (EBW) of the EUT is measured with
the device placed in the test mode(s) with the shortest available frame length and minimum frame spacing. The
20 dB EBW is measured as the max-held peak-detected signal when the IF bandwidth is greater than or equal to
1% of the receiver span. For complex modulations other than ASK and FSK, the 99% emission bandwidth per IC
test procedures has a different result, and is also reported. The test equipment employed includes RSFSV30001,
BILOG3142.
Measurement Results The details and results of testing the EUT are summarized in Table 5. Plots showing the
measurements made to obtain these values are provided in Figure 6.
Table 5: Fundamental Emission Bandwidth.
Detector
Pk
IF Bandwidth
10 kHz
Video Bandwidth
30 kHz
Modulation
FSK
FSK
Center Frequency
(MHz)
312.10
314.35
20 dB EBW
(MHz)
0.110
0.111
Test Date:
Test Engineer:
EUT:
EUT Mode:
Meas. Distance:
20-Jan-18
Joseph Brunett
TRW Toy Tx
Modulated
10 cm
FCC/IC
EBW Limit
(MHz)
0.7803
0.785875
99% OBW
(MHz)
0.119
0.118
Figure 6: Fundamental Emission Bandwidth.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 14 of 18
Date: January 28, 2018
4.2.3
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Fundamental Emission Field Strength
Test Setup & Procedure The test equipment and facilities were setup in accordance with the standards and
procedures listed in Section 2.1. Environmental conditions were set at the appropriate temperature and thermal
balance was checked with a thermocouple based probe. Fundamental emissions are measured at the regulatory
distance on our OATS. The test equipment employed includes HP8546A, BILOG3142.
Measurement Results
The details and results of testing the EUT are summarized in Table 6.
Table 6: Fundamental Emission Field Strength.
Frequency Range
25 MHz ≤ f ≤ 1 000 MHz
f > 1 000 MHz
f > 1 000 MHz
Det
Pk/QPk
Pk
Avg
IF Bandwidth
120 kHz
1 MHz
1 MHz
Video Bandwidth
300 kHz
3 MHz
10 kHz
19-Jan-18
Test Date:
Test Engineer:
EUT:
EUT Mode:
Gordon Helm
TRW Toy Tx
CW
Meas. Distance:
3 meters
FCC/IC
Freq.
MHz
312.1
312.1
312.1
314.4
Ant.
Used
BILO3142
Ant.
Pol.
Table Azim.
BILO3142
BILO3142
160.0
240.0
deg
160.0
Ka
Ant Height
1.3
dB/m
Kg
dB
17.3
-1.2
71.9
1.3
1.8
1.3
17.3
17.3
17.3
-1.2
-1.2
-1.2
BILO3142
160.0
BILO3142
240.0
314.4
1.8
17.3 -1.2
*Avg data computed from Peak Measured Data and EUT Duty Cycle. EUT in CW mode.
E3(Pk)** E3(Avg)*
dBµV/m dBµV/m
FCC/IC E3(Pk)
Lim. dBµV/m
FCC/IC E3(Avg)
Lim. dBµV/m
Pass
dB
71.9
95.4
75.4
3.5
side (key in)
71.9
69.4
70.5
71.9
69.4
70.5
95.4
95.4
95.4
75.4
75.4
75.4
3.5
6.0
4.9
side (key out)
end (key in)
side (key in)
68.0
68.0
95.4
75.4
7.4
end (key in)
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Comments
Page 15 of 18
Date: January 28, 2018
4.3
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Unintentional Emissions
4.3.1
Transmit Chain Spurious Emissions
Test Setup & Procedure The test equipment and facilities were setup in accordance with the standards and
procedures listed in Section 2.1. Environmental conditions were set at the appropriate temperature and thermal
balance was checked with a thermocouple based probe. Spurious radiated emissions measurements are performed to
10 times the highest fundamental operating frequency. The test equipment employed includes HP8546A, BILOG3142,
RH3115.
Measurement Results
The details and results of testing the EUT are summarized in Table 7.
Table 7: Transmit Chain Spurious Emissions.
Frequency Range
25 MHz ≤ f ≤ 1 000 MHz
Det
Pk/QPk
IF Bandwidth
120 kHz
Video Bandwidth
300 kHz
f > 1 000 MHz
Pk/Avg
1 MHz
3 MHz
Test Date:
Gordon Helm
EUT:
TRW Toy Tx
EUT Mode:
Meas. Distance:
Freq.
Ant.
Ant. Table Azim.
Transmitter Unintentional Spurious Emissions
Ka
Kg
E3(Pk)** E3(Avg)
Ant Height
dBµV/m dBµV/m
19-Jan-18
Test Engineer:
CW
3 meters
FCC/IC
FCC/IC E3lim (Pk)
FCC/IC E3lim (Avg)
Pass
MHz
Used
Pol.
deg
dB
dBµV/m
dBµV/m
dB
624.2
BILO3142
180.0
1.1
dB/m
19.9
-2.1
26.7
26.7
75.4
55.4
28.7
max all
Comments
624.2
BILO3142
240.0
1.9
19.9
-2.1
27.4
27.4
75.4
55.4
28.0
max all
936.3
BILO3142
350.0
1.7
25.2
-2.9
31.5
31.5
75.4
55.4
23.9
max all
936.3
BILO3142
80.0
1.1
25.2
-2.9
29.9
29.9
75.4
55.4
25.5
max all
1248.4
1560.5
RH3115
H/V
20.0
1.3
RH3115
H/V
90.0
2.1
26.6
27.2
-1.4
-1.7
37.0
40.0
37.0
40.0
75.4
75.4
55.4
55.4
18.4
15.4
max all
max all
1872.6
2184.7
RH3115
H/V
H/V
180.0
180.0
1.5
RH3115
1.0
27.8
28.3
-2.0
-2.2
37.0
42.0
37.0
42.0
75.4
75.4
55.4
55.4
18.4
13.4
max all
max all
2496.8
RH3115
H/V
90.0
1.8
28.7
-2.4
44.0
44.0
75.4
55.4
2808.9
RH3115
H/V
270.0
1.8
29.1
-2.6
43.0
43.0
75.4
55.4
11.4
12.4
max all, noise
10
11
3121.0
RH3115
H/V
270.0
1.8
29.4
-2.8
42.0
42.0
75.4
55.4
13.4
max all, noise
13
628.7
BILO3142
180.0
1.1
20.0
-2.1
26.7
26.7
75.4
55.4
28.7
max all
14
628.7
BILO3142
240.0
1.9
20.0
-2.1
24.7
24.7
75.4
55.4
30.7
max all
15
943.1
BILO3142
350.0
1.7
25.1
-3.0
31.5
31.5
75.4
55.4
23.9
max all
16
943.1
BILO3142
80.0
1.1
25.1
-3.0
29.9
29.9
75.4
55.4
25.5
max all
17
1257.4
RH3115
H/V
20.0
1.3
26.6
-1.5
37.0
37.0
75.4
55.4
18.4
max all
18
1571.8
RH3115
H/V
90.0
2.1
27.2
-1.7
40.0
40.0
75.4
55.4
15.4
max all
19
1886.1
RH3115
H/V
180.0
1.5
27.8
-2.0
37.0
37.0
75.4
55.4
18.4
max all
20
2200.5
RH3115
H/V
180.0
1.0
28.3
-2.2
42.0
42.0
75.4
55.4
13.4
max all
21
2514.8
RH3115
H/V
90.0
1.8
28.7
-2.4
44.0
44.0
75.4
55.4
11.4
max all, noise
22
2829.2
RH3115
H/V
270.0
1.8
29.1
-2.6
43.0
43.0
75.4
55.4
12.4
max all, noise
23
3143.5
RH3115
H/V
270.0
1.8
29.4
-2.8
42.0
42.0
75.4
55.4
13.4
max all, noise
max all, noise
12
*Avg data computed from Peak Measured Data and EUT Duty Cycle. EUT in CW mode.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 16 of 18
Date: January 28, 2018
4.3.2
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Radiated Digital Spurious
The results for the measurement of digital spurious emissions are not reported herein as all digital emissions were
greater than 20 dB below the regulatory limit. Radiation from digital components was measured to 4 GHz, or to
five times the maximum digital component operating frequency, whichever is greater.
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 17 of 18
Date: January 28, 2018
Prepared For: TRW Automotive
Report No.: TRWTX-1702216TX
Measurement Uncertainty and Accreditation Documents
The maximum values of measurement uncertainty for the laboratory test equipment and facilities associated with
each test are given in the table below. This uncertainty is computed for a 95.45% confidence level based on a coverage
factor of k = 2.
Table 8: Measurement Uncertainty.
Measured Parameter
Radio Frequency
Conducted Emm. Amplitude
Radiated Emm. Amplitude (30 − 200 MHz)
Radiated Emm. Amplitude (200 − 1000 MHz)
Radiated Emm. Amplitude (f > 1000 MHz)
† Ref:
Measurement Uncertainty†
±(fM kr /10 + RBW/10 + (SP N/(P T S − 1))/2 + 1 Hz)
±1.9 dB
±4.0 dB
±5.2 dB
±3.7 dB
CISPR 16-4-2:2011+A1:2014
Figure 7: Accreditation Documents
Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USA
Page 18 of 18
Download: 73T RKE Transmitter Test Report  TRW Inc
Mirror Download [FCC.gov]73T RKE Transmitter Test Report  TRW Inc
Document ID3741415
Application IDZvv9sc8SawKk05X12JbfSw==
Document DescriptionTest Report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize239.93kB (2999083 bits)
Date Submitted2018-02-05 00:00:00
Date Available2018-02-06 00:00:00
Creation Date2018-02-05 07:19:43
Producing SoftwarepdfTeX-1.40.18
Document Lastmod2018-02-05 07:22:21
Document TitleTest Report
Document CreatorLaTeX with hyperref package

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.5
Linearized                      : No
Page Count                      : 18
XMP Toolkit                     : NitroPro 9.5
Modify Date                     : 2018:02:05 07:22:21-05:00
Page Mode                       : UseOutlines
Create Date                     : 2018:02:05 07:19:43-05:00
Title                           :
Creator                         : LaTeX with hyperref package
Producer                        : pdfTeX-1.40.18
Author                          :
Subject                         :
Trapped                         : False
PTEX Fullbanner                 : This is MiKTeX-pdfTeX 2.9.6354 (1.40.18)
