FCC ID GT3FC016
WLAN Complete Module
by SMK Corporation
Grantee Code: GT3 Product Code: FC016
Latest application date: 2018-02-23
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5320 MHz | Class II permissive change or modification of presently authorized equipment | 2018-02-23 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2018-02-23 |
| 5180-5320 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-09 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2015-07-31 |
| 5180-5320 MHz | Class II permissive change or modification of presently authorized equipment | 2015-07-31 |
| 2412-2462 MHz | Original Equipment | 2012-07-31 |
| 5180-5320 MHz | Original Equipment | 2012-07-31 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-02-09 | PDF 595.7 KB |
| User Manual | Users Manual | 2015-07-31 | PDF 142.4 KB |
| User manual for VRL4149-0601F | Users Manual | 2012-07-31 | PDF 558.6 KB |
| Internal Photo | Internal Photos | 2012-07-31 | PDF 184 KB |
| External Photo | External Photos | 2012-07-31 | PDF 419.4 KB |
| Label Drawing | ID Label/Location Info | 2012-07-31 | PDF 959.8 KB |
| Label Location | ID Label/Location Info | 2012-07-31 | PDF 419.4 KB |
| 03 Short-Term Confidential_FCC SAR Setup Photo | Test Setup Photos | 2018-03-16 | PDF 816.5 KB |
| FCC Test Setup Photo_NII | Test Setup Photos | 2016-02-09 | PDF 844.8 KB |
| FCC SAR Setup Photo | Test Setup Photos | 2015-07-31 | PDF 343.1 KB |
| Test Setup Photo_15C | Test Setup Photos | 2012-07-31 | PDF 202.5 KB |
| Test Setup Photo_15E | Test Setup Photos | 2012-07-31 | PDF 211.4 KB |
| Test Setup Photo_DFS | Test Setup Photos | 2012-07-31 | PDF 213.3 KB |
| 03 FCC SAR Report-1 | Test Report | 2018-02-23 | PDF 381.8 KB |
| 03 FCC SAR Report-2 | Test Report | 2018-02-23 | PDF 2.3 MB |
| FCC Test Report_NII | Test Report | 2016-02-09 | PDF 890.2 KB |
| Report_15C | Test Report | 2012-07-31 | PDF 501.7 KB |
| Report_15E-Revised2 | Test Report | 2012-07-31 | PDF 429.4 KB |
| Report_DFS | Test Report | 2012-07-31 | PDF 689.2 KB |
| Test Data&Instruments1_15E | Test Report | 2012-07-31 | PDF 1.2 MB |
| Test Data&Instruments2_15E-Revised2 | Test Report | 2012-07-31 | PDF 2.7 MB |
| Test Data&Instruments_15C | Test Report | 2012-07-31 | PDF 2.7 MB |
| 02 FCC Authorization Letter | Cover Letter(s) | 2018-02-23 | PDF 42.9 KB |
| 02 FCC Class II Permissive Change Letter | Cover Letter(s) | 2018-02-23 | PDF 88.3 KB |
| 02 FCC Declaration of Professional Installation | Cover Letter(s) | 2018-02-23 | PDF 33.3 KB |
| 02 FCC Request for Confidentiality Letter | Cover Letter(s) | 2018-02-23 | PDF 35.8 KB |
| 02 FCC Request for Short-term Confidentiality Letter | Cover Letter(s) | 2018-02-23 | PDF 36.6 KB |
| FCC Authorization Letter | Cover Letter(s) | 2016-02-09 | PDF 33.2 KB |
| FCC Class II Permissive Change Letter | Cover Letter(s) | 2016-02-09 | PDF 49.8 KB |
| FCC Declaration Letter of FCC 14-30_Old rule or New rule | Cover Letter(s) | 2016-02-09 | PDF 24.7 KB |
| FCC Declaration of Professional Installation | Cover Letter(s) | 2016-02-09 | PDF 23.9 KB |
| FCC LMA Letter | Cover Letter(s) | 2016-02-09 | PDF 74.8 KB |
| FCC Request for Confidentiality Letter | Cover Letter(s) | 2016-02-09 | PDF 27.5 KB |
| FCC Authorization Letter | Cover Letter(s) | 2015-07-31 | PDF 29.5 KB |
| FCC Class II Permissive Change Letter | Cover Letter(s) | 2015-07-31 | PDF 43.5 KB |
| FCC Declaration Letter of FCC 14-30_Old rule or New rule | Cover Letter(s) | 2015-07-31 | PDF 21.7 KB |
| FCC Declaration of Professional Installation | Cover Letter(s) | 2015-07-31 | PDF 21.3 KB |
| FCC LMA Letter | Cover Letter(s) | 2015-07-31 | PDF 66.3 KB |
| FCC Request for Confidentiality Letter | Cover Letter(s) | 2015-07-31 | PDF 25.3 KB |
| Agent Letter | Cover Letter(s) | 2012-07-31 | PDF 36.9 KB |
| LMA letter | Cover Letter(s) | 2012-07-31 | PDF 95 KB |
| Request for Confidentiality | Cover Letter(s) | 2012-07-31 | PDF 33.1 KB |
| FCC SAR Report | RF Exposure Info | 2015-07-31 | PDF 667.4 KB |
| FCC SAR Report Data | RF Exposure Info | 2015-07-31 | PDF 2.1 MB |
| RF Exposure sheet | RF Exposure Info | 2012-07-31 | PDF 79.2 KB |
| (Confidential) Theory of Operation-Software Security Metadata only | Operational Description | PDF 42.6 KB | |
| (Confidential) Theory of Operation-Software Security Metadata only | Operational Description | PDF 42.7 KB | |
| 04 Confidential_Theory of Operation-Host Specification_M292A_M292C Metadata only | Operational Description | PDF 665.9 KB | |
| 04 Confidential_Theory of Operation-Host Specification_M316A_M316C Metadata only | Operational Description | PDF 1,019.8 KB |
Application Information
| Application ID | HBYVxyMOpR/C+zckNgwmUA== |
|---|---|
| Final Action Date | 2018-02-23 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0015266521 |
| Model | FC016 |
| Frequency Range | 5180-5320 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | WLAN Complete Module |
| Responsible Party | Akio Nakanishi, Manager, aki-naka@smk.co.jp  , 81-3-3785-5058 |
| Agent | Yoshihisa Yoshihisa Yoshihisa, UL Japan, Inc., Yoshihisa.Maeda@ul.com  , 81-596-24-8999 |
| Technical Contact | Toyokazu Imamura, UL Japan, Inc., Toyokazu.Imamura@ul.com , 81-463-50-6400 |
| Test Firm | Tetsuya Hashimoto, UL Japan, Inc. Shonan EMC EMC Lab., Tetsuya.Hashimoto@jp.ul.com  , +81-596-24-8116 |
| TCB Email | emc.jp@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 03/16/2018 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted. For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A, M292C, M292A, M316A and M316C). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| HBYVxyMOpR/C+zckNgwmUA== | 2018-02-23 | Class II permissive change or modification of presently authorized equipment |
| CWOiW/o4gZ7+6BMUWKuCTQ== | 2018-02-23 | Class II permissive change or modification of presently authorized equipment |
| 3vyFC9Zc//NLOFPskuB8EA== | 2016-02-09 | Class II permissive change or modification of presently authorized equipment |
| JW5XH3cEFu+j1Y3J5Bvz0A== | 2015-07-31 | Class II permissive change or modification of presently authorized equipment |
| +We68BOQt8mWnEIXxiGmhA== | 2015-07-31 | Class II permissive change or modification of presently authorized equipment |
| SJHbSxRaXgUiS2jw0DmLyw== | 2012-07-31 | Original Equipment |
| Ex1vczkMzi9PKzAFSk98TQ== | 2012-07-31 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules | Grant Notes |
|---|---|---|---|
| 2412-2462 MHz | 0.1462000 | 15C | CC |
| 2412-2462 MHz | 0.1462 | 15C | CC |
| 5180-5320 MHz | 0.0183 | 15E | 39, CC, ND |
| 5180-5320 MHz | 0.0183 | 15E | 38, CC, ND |
| 5180-5320 MHz | 0.0183 | 15E | CC |
| 5500-5700 MHz | 0.0103 | 15E | 39, CC, ND |
| 5500-5700 MHz | 0.0103 | 15E | 38, CC, ND |
| 5500-5700 MHz | 0.0103 | 15E | CC |
| 5745-5825 MHz | 0.0436 | 15C | 39, CC |
| 5745-5825 MHz | 0.0436 | 15C | CC |
| 5745-5825 MHz | 0.0111 | 15E | 38, CC |
Grants
TCB Grant - Application SJHbSxRaXgUiS2jw0DmLyw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 07/31/2012 Application Dated: 07/31/2012 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Mitsuhiko Goto , Gneral Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.1462 | ||
| CC | 15C | 5745.0 - 5825.0 | 0.0436 |
| Limited Modular Approval. Output power listed is Conducted. The antenna shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Use in portable RF exposure conditions must require additional filing for SAR compliance. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application SJHbSxRaXgUiS2jw0DmLyw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 07/31/2012 Application Dated: 07/31/2012 |
| Attention: Mitsuhiko Goto , Gneral Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.1462 | ||
| CC | 15C | 5745.0 - 5825.0 | 0.0436 |
| Limited Modular Approval. Output power listed is Conducted. The antenna shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Use in portable RF exposure conditions must require additional filing for SAR compliance. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 07/31/2015 Application Dated: 07/30/2015 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.1462 | ||
| 39 CC | 15C | 5745.0 - 5825.0 | 0.0436 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted(Peak). For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| 39: | This sub-band complies with the new rules for U-NII devices adopted under Docket No. 13-49. This device may not be sold or marketed after June 1, 2016, unless all grant-listed U-NII sub-bands demonstrate compliance with Docket No. 13-49. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application JW5XH3cEFu+j1Y3J5Bvz0A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 07/31/2015 Application Dated: 07/30/2015 |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.1462 | ||
| 39 CC | 15C | 5745.0 - 5825.0 | 0.0436 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted(Peak). For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| 39: | This sub-band complies with the new rules for U-NII devices adopted under Docket No. 13-49. This device may not be sold or marketed after June 1, 2016, unless all grant-listed U-NII sub-bands demonstrate compliance with Docket No. 13-49. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 02/23/2018 Application Dated: 02/23/2018 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC ND | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| 38 CC ND | 15E | 5500.0 - 5700.0 | 0.0103 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0111 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted. For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A, M292C, M292A, M316A and M316C). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application HBYVxyMOpR/C+zckNgwmUA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 02/23/2018 Application Dated: 02/23/2018 |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC ND | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| 38 CC ND | 15E | 5500.0 - 5700.0 | 0.0103 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0111 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted. For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A, M292C, M292A, M316A and M316C). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 07/31/2012 Application Dated: 07/31/2012 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Mitsuhiko Goto , Gneral Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| CC | 15E | 5500.0 - 5700.0 | 0.0103 |
| Limited Modular Approval. Output power listed is Conducted. The antenna shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Use in portable RF exposure conditions must require additional filing for SAR compliance. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. Operations in 5.15-5.25 GHz band are for indoor use only. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and Order FCC 03-287 as a Client only without Radar Detection. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application Ex1vczkMzi9PKzAFSk98TQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 07/31/2012 Application Dated: 07/31/2012 |
| Attention: Mitsuhiko Goto , Gneral Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| CC | 15E | 5500.0 - 5700.0 | 0.0103 |
| Limited Modular Approval. Output power listed is Conducted. The antenna shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Use in portable RF exposure conditions must require additional filing for SAR compliance. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. Operations in 5.15-5.25 GHz band are for indoor use only. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and Order FCC 03-287 as a Client only without Radar Detection. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 02/23/2018 Application Dated: 02/23/2018 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.1462 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted(Peak). For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A, M292C, M292A, M316A and M316C). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application CWOiW/o4gZ7+6BMUWKuCTQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 02/23/2018 Application Dated: 02/23/2018 |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.1462 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted(Peak). For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A, M292C, M292A, M316A and M316C). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 02/09/2016 Application Dated: 02/09/2016 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC ND | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| 38 CC ND | 15E | 5500.0 - 5700.0 | 0.0103 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0111 |
| Class II Permissive Change based on FCC14-30. Limited Modular Approval. Output power listed is Conducted. The antenna shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in previous filing (Host system : M327A). Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The highest reported SAR value is 0.73 W/kg : Body-worn. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application 3vyFC9Zc//NLOFPskuB8EA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 02/09/2016 Application Dated: 02/09/2016 |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC ND | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| 38 CC ND | 15E | 5500.0 - 5700.0 | 0.0103 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0111 |
| Class II Permissive Change based on FCC14-30. Limited Modular Approval. Output power listed is Conducted. The antenna shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in previous filing (Host system : M327A). Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The highest reported SAR value is 0.73 W/kg : Body-worn. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 07/31/2015 Application Dated: 07/30/2015 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 39 CC ND | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| 39 CC ND | 15E | 5500.0 - 5700.0 | 0.0103 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted. For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. Operations in 5.15-5.25 GHz band are for indoor use only. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| 39: | This sub-band complies with the new rules for U-NII devices adopted under Docket No. 13-49. This device may not be sold or marketed after June 1, 2016, unless all grant-listed U-NII sub-bands demonstrate compliance with Docket No. 13-49. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application +We68BOQt8mWnEIXxiGmhA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 07/31/2015 Application Dated: 07/30/2015 |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC016 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | WLAN Complete Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 39 CC ND | 15E | 5180.0 - 5320.0 | 0.0183 | ||
| 39 CC ND | 15E | 5500.0 - 5700.0 | 0.0103 |
| Class II Permissive Change to add specific portable configuration host described in the filing. Limited Modular Approval. Output power listed is Conducted. For professional installation only. Device shall not be sold to general public. Use in portable RF exposure conditions is limited to the specific product and antenna configuration evaluated in this filing (Host system : M327A). When used in mobile applications except the conditions shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Host systems must provide regulated supply voltages to the module. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter. Operations in 5.15-5.25 GHz band are for indoor use only. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and KDB 905462 D01 as a Client only without Radar Detection. The highest reported SAR values are: 0.73 W/kg : Body-worn. |
| 39: | This sub-band complies with the new rules for U-NII devices adopted under Docket No. 13-49. This device may not be sold or marketed after June 1, 2016, unless all grant-listed U-NII sub-bands demonstrate compliance with Docket No. 13-49. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: |
