FCC ID GT3FC022
Bluetooth Smart Module
by SMK Corporation
Grantee Code: GT3 Product Code: FC022
Latest application date: 2015-11-10
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-11-10 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-11-10 | PDF 46.7 KB |
| Internal Photo | Internal Photos | 2015-11-10 | PDF 49 KB |
| External Photo | External Photos | 2015-11-10 | PDF 48.9 KB |
| Label and Location | ID Label/Location Info | 2015-11-10 | PDF 31 KB |
| FCC Test Setup Photo_DTS | Test Setup Photos | 2015-11-10 | PDF 545 KB |
| FCC Test Report_DTS | Test Report | 2015-11-10 | PDF 744.3 KB |
| FCC Authorization Letter | Cover Letter(s) | 2015-11-10 | PDF 35.6 KB |
| FCC MA Letter | Cover Letter(s) | 2015-11-10 | PDF 70 KB |
| FCC Request for Confidentiality Letter | Cover Letter(s) | 2015-11-10 | PDF 30.3 KB |
| FCC RF Exposure_DTS | RF Exposure Info | 2015-11-10 | PDF 112.6 KB |
| (Confidential) Block Diagram Metadata only | Block Diagram | PDF 117.5 KB | |
| (Confidential) Block Diagram_RF Metadata only | Block Diagram | PDF 280.2 KB | |
| (Confidential) Schematics Metadata only | Schematics | PDF 37.4 KB | |
| (Confidential) Theory of Operation-Antenna Specification Metadata only | Operational Description | PDF 3 MB | |
| (Confidential) Theory of Operation-Specification Metadata only | Operational Description | PDF 487.2 KB | |
| (Confidential) Parts List Metadata only | Parts List/Tune Up Info | PDF 78.1 KB |
Application Information
| Application ID | 5RKBH13F6O7a+lcVzjsxLQ== |
|---|---|
| Final Action Date | 2015-11-10 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0015266521 |
| Model | FC022 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Bluetooth Smart Module |
| Responsible Party | Akio Nakanishi, Manager, aki-naka@smk.co.jp  , 81-3-3785-5058 |
| Agent | Yoshihisa Yoshihisa Yoshihisa, UL Japan, Inc., Yoshihisa.Maeda@ul.com  , 81-596-24-8999 |
| Technical Contact | Akio Hayashi, UL Japan, Inc., Akio.Hayashi@ul.com , 81-463-50-6400 |
| Test Firm | Tetsuya Hashimoto, UL Japan, Inc. Shonan EMC EMC Lab., Tetsuya.Hashimoto@jp.ul.com  , +81-596-24-8116 |
| TCB Email | emc.jp@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Output power listed is Conducted(Peak). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 5RKBH13F6O7a+lcVzjsxLQ== | 2015-11-10 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0028000 | 15C |
Grants
TCB Grant - Application 5RKBH13F6O7a+lcVzjsxLQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 11/10/2015 Application Dated: 11/10/2015 |
| SMK Corporation |
| 5-5 Togoshi 6-chome |
| Shinagawa-ku Tokyo, 142-8511 Japan |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC022 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Bluetooth Smart Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0028 |
| Single Modular Approval. Output power listed is Conducted(Peak). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
EAS Grant - Application 5RKBH13F6O7a+lcVzjsxLQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SMK Corporation 5-5 Togoshi 6-chome Shinagawa-ku Tokyo, 142-8511 Japan |
Date of Grant: 11/10/2015 Application Dated: 11/10/2015 |
| Attention: Akio Nakanishi , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | GT3FC022 |
| Name of Grantee: | SMK Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Bluetooth Smart Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0028 |
| Single Modular Approval. Output power listed is Conducted(Peak). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
| Mail To: |
