KPMT150 VHF Data Radio External Photos - FCC ID H78KPMT150

FCC ID H78KPMT150

External Rear View Photo

VHF Data Radio

by KP Electronic Systems Ltd

External Rear View Photo

Document Details

FCC IDH78KPMT150
Document ID84739
Document TypeExternal Photos
DescriptionExternal Rear View Photo
ApplicantKP Electronic Systems Ltd
Equipment ClassVHF Data Radio
Product CodeKPMT150
Application IDcbIs+bH24iqw8XGoQXMZnA==
Application PurposeOriginal Equipment
Application Date2001-01-05
Frequency Range148-174 MHz
FRN0009595398
Test FirmTimco Engineering, Inc.
Certified ByS.S. Sanders Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2000-02-02
Available2001-01-05
Pages0
File TypeJPEG Image
File Size43820
File SHA-256149baec0fac0dd6a36d769a6f55aa9dcf0c1ba5c8a0eb92c44c2ddb2aa511a39
FCC.gov SourcesFCC.gov 84739
