FCC ID H78KPMT2W
VHF AUTOMATIC METER READING TRANSCEIVER W 2.4 GHz TX
by KP Electronic Systems Ltd
Grantee Code: H78 Product Code: KPMT2W
Latest application date: 2019-10-01
Device Images
FCC ID Device Details
| FCC ID | H78KPMT2W |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | H78 |
| Product Code | KPMT2W |
| Applicant Business | KP Electronic Systems Ltd 🇮🇱 |
| Equipment Class | VHF AUTOMATIC METER READING TRANSCEIVER W 2.4 GHz TX |
| Test Firm | Timco Engineering, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 151-156 MHz | Class II permissive change or modification of presently authorized equipment | 2019-10-01 |
| 151-156 MHz | Class II permissive change or modification of presently authorized equipment | 2017-04-11 |
| 2433 MHz | Original Equipment | 2015-10-26 |
| 172.5-173.5 MHz | Original Equipment | 2015-10-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-04-11 | PDF 368.7 KB |
| User Manual | Users Manual | 2015-10-26 | PDF 355.5 KB |
| Internal Photos | Internal Photos | 2020-03-29 | PDF 592.3 KB |
| Internal Photos | Internal Photos | 2017-04-11 | PDF 5.8 MB |
| Internal Photos | Internal Photos | 2015-10-26 | PDF 1.2 MB |
| External Photos | External Photos | 2017-04-11 | PDF 2.2 MB |
| External Photos | External Photos | 2015-10-26 | PDF 356.3 KB |
| External photos | External Photos | 2015-10-26 | PDF 356.3 KB |
| Label location | ID Label/Location Info | 2015-10-26 | PDF 31.4 KB |
| Label sample | ID Label/Location Info | 2015-10-26 | PDF 66.8 KB |
| Test Setup Photos | Test Setup Photos | 2019-10-01 | PDF 146.4 KB |
| Test Setup Photos | Test Setup Photos | 2017-04-11 | PDF 1.1 MB |
| Test set up photos | Test Setup Photos | 2015-10-26 | PDF 610.6 KB |
| Test set up photos | Test Setup Photos | 2015-10-26 | PDF 1.8 MB |
| Test Report | Test Report | 2019-10-01 | PDF 456.9 KB |
| Test Report | Test Report | 2017-04-11 | PDF 1.6 MB |
| Test Report | Test Report | 2015-10-26 | PDF 782.6 KB |
| Test Report | Test Report | 2015-10-26 | PDF 366.3 KB |
| Attestation Statement | Attestation Statements | 2017-04-11 | PDF 86.8 KB |
| Attestation statement per 90.203 | Attestation Statements | 2015-10-26 | PDF 202.6 KB |
| C2PC Letter | Cover Letter(s) | 2019-10-01 | PDF 82.4 KB |
| Confidential Request Letter | Cover Letter(s) | 2019-10-01 | PDF 86.1 KB |
| POA | Cover Letter(s) | 2019-10-01 | PDF 106.8 KB |
| Class II Permissive Change Letter | Cover Letter(s) | 2017-04-11 | PDF 27.8 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-04-11 | PDF 89 KB |
| POA | Cover Letter(s) | 2017-04-11 | PDF 85.5 KB |
| Confidentiality request letter | Cover Letter(s) | 2015-10-26 | PDF 185.6 KB |
| RF Exposure | RF Exposure Info | 2017-04-11 | PDF 176.9 KB |
| Parts List | Parts List/Tune Up Info | 2015-10-26 | PDF 70.1 KB |
| Rf Exposure Information | RF Exposure Info | 2015-10-26 | PDF 182.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 427.8 KB | |
| Block Diagram - Schematic Back End Metadata only | Block Diagram | PDF 61.5 KB | |
| Block Diagram - Schematic Front End Metadata only | Block Diagram | PDF 81.8 KB | |
| Block diagram Metadata only | Block Diagram | PDF 427.8 KB | |
| Schematic - Frequency Synthesizer Metadata only | Schematics | PDF 472.2 KB | |
| Schematic - Modulation Decoding Metadata only | Schematics | PDF 484.7 KB | |
| Schematic - Power supply Metadata only | Schematics | PDF 1 MB | |
| Schematic - Power supply and Voltage switches Metadata only | Schematics | PDF 490.5 KB | |
| Schematic - Power supply and voltage switches Metadata only | Schematics | PDF 490.5 KB | |
| Schematic - RF Amplifier Metadata only | Schematics | PDF 396 KB | |
| Schematic - Short Range Radio Metadata only | Schematics | PDF 487.9 KB | |
| Schematics Metadata only | Schematics | PDF 2 MB | |
| Schematics - RF amplifier Metadata only | Schematics | PDF 396 KB | |
| Schematics - power supply Metadata only | Schematics | PDF 1 MB | |
| Schematics Back End Metadata only | Schematics | PDF 61.5 KB | |
| Schematics Front End Metadata only | Schematics | PDF 81.8 KB | |
| Schematics MT2PITM Metadata only | Schematics | PDF 81.7 KB | |
| Schematics MT2WM Metadata only | Schematics | PDF 81.6 KB | |
| Schematics UHF radio (1) Metadata only | Schematics | PDF 81.6 KB | |
| Schematics UHF radio (2) Metadata only | Schematics | PDF 87.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 1.3 MB | |
| Operational Description Metadata only | Operational Description | PDF 1.1 MB | |
| Part List Metadata only | Parts List/Tune Up Info | PDF 73.4 KB | |
| Parts List MT2WM Metadata only | Parts List/Tune Up Info | PDF 59.1 KB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 936.7 KB | |
| Tuning Procedure Metadata only | Parts List/Tune Up Info | PDF 608.1 KB |
Application Information
| Application ID | UghcXEkodVlqxfcHCUIaKg== |
|---|---|
| Final Action Date | 2019-10-01 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0009595398 |
| Model | KPMT2W |
| Frequency Range | 151-156 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | VHF AUTOMATIC METER READING TRANSCEIVER W 2.4 GHz TX |
| Responsible Party | Yoram Kenig, kpelectron@aol.com  , 215 542-7460 |
| Test Firm | Bruno Clavier, Timco Engineering, Inc., bruno@timcoengr.com  , 352-472-5500 |
| TCB Email | tei@timcoengr.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 03/29/2020 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is ERP. This device complies with the Federal Communications Commission (FCC) RF Exposure limits for General Population/Uncontrolled Environment. The antenna for this device is a Helical antenna. The device must operate within a minimum separation distance of 28 cm (11 inches) from all persons as specified in this filing. C2PC: There have been no changes to the circuit except the PA chip was changed and the device is now providing 6.5Vdc instead of 12.8Vdc. The change is in the internal battery package. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| UghcXEkodVlqxfcHCUIaKg== | 2019-10-01 | Class II permissive change or modification of presently authorized equipment |
| LHEFJP72X9QQOR7+A/zx/w== | 2017-04-11 | Class II permissive change or modification of presently authorized equipment |
| ee2sKtZ7VqAfkMGE9B1DXA== | 2015-10-26 | Original Equipment |
| /20Aq6Tm8pjolcQU/ajYmQ== | 2015-10-26 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application UghcXEkodVlqxfcHCUIaKg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/01/2019 Application Dated: 10/01/2019 |
| KP Electronic Systems Ltd |
| P. O. Box 42 |
| Tefen Industrial Park, 24959 Israel |
| Attention: Yoram Kenig |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | H78KPMT2W |
| Name of Grantee: | KP Electronic Systems Ltd |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | VHF AUTOMATIC METER READING TRANSCEIVER W 2.4 GHz TX |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 90 | 172.5 - 173.5 | 2.0 | 0.73 PM | 2K55F1D | |
| 90 | 151.0 - 156.0 | 2.0 | 0.73 PM | 2K46F1D |
| Output power listed is ERP. This device complies with the Federal Communications Commission (FCC) RF Exposure limits for General Population/Uncontrolled Environment. The antenna for this device is a Helical antenna. The device must operate within a minimum separation distance of 28 cm (11 inches) from all persons as specified in this filing. C2PC: There have been no changes to the circuit except the PA chip was changed and the device is now providing 6.5Vdc instead of 12.8Vdc. The change is in the internal battery package. |
