604250R Flasher External Photos - FCC ID HAP604250R
FCC ID HAP604250R
Bottom view
Flasher
Document Details
| FCC ID | HAP604250R |
|---|---|
| Document ID | 99232 |
| Document Type | External Photos |
| Description | Bottom view |
| Applicant | Echo Toys Ltd |
| Equipment Class | Flasher |
| Product Code | 604250R |
| Application ID | SiBoMtqae6IcHCws8h1TxQ== |
| Application Purpose | Original Equipment |
| Application Date | 2000-06-14 |
| Frequency Range | 49.82-49.9 MHz |
| FRN | 0006267157 |
| Test Firm | International Elect. Cert. Centre |
| Certified By | Elvin K. B. Lau Director |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 2000-05-09 |
| Available | 2000-06-14 |
| Pages | 0 |
| File Type | JPEG Image |
| File Size | 53774 |
| File SHA-256 | cabfb7553e10b3c0da5f035d66f01c3ad2d0ca52688c06499e2931f3435f587b |
| FCC.gov Sources | FCC.gov 99232 |
