91252T49 49 MHz Radio Transmitter Block Diagram - FCC ID HAP91252T49
FCC ID HAP91252T49
block diagram
49 MHz Radio Transmitter
Document preview loads when visible.
Document Details
| FCC ID | HAP91252T49 |
|---|---|
| Document ID | 312221 |
| Document Type | Block Diagram |
| Description | block diagram |
| Document Title | CAM output |
| Applicant | Echo Toys Ltd |
| Equipment Class | 49 MHz Radio Transmitter |
| Product Code | 91252T49 |
| Application ID | rKah0bfBwh0/IkQyXcprGg== |
| Application Purpose | Original Equipment |
| Application Date | 2003-03-21 |
| Frequency Range | 49.82-49.9 MHz |
| FRN | 0006267157 |
| Test Firm | SGS-CSTC Standards Technical Services Co., Ltd |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-03-21 |
| Available | 2003-03-21 |
| Created | 2003-03-08 |
| Modified | 2003-03-17 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 23377 |
| File SHA-256 | 19be8b87f88daabd99e62c3e47824c52ed9ed8d82098815db2e8e409bd91efb5 |
| PDF Metadata Author | angel |
| PDF Metadata Producer | pdfFactory Pro v1.57 (Windows 98 Chinese) angel |
| FCC.gov Sources | FCC.gov 312221 |
