CT40PL1N Mobile Computer Test Setup Photos - FCC ID HD5-CT40PL1N

FCC ID HD5-CT40PL1N

Test setup DFS

Mobile Computer

by Honeywell International Inc

Document preview loads when visible.

Document Details

FCC IDHD5-CT40PL1N
Document ID4890735
Document TypeTest Setup Photos
DescriptionTest setup DFS
ApplicantHoneywell International Inc
Equipment ClassMobile Computer
Product CodeCT40PL1N
Application ID8He4HzH/F0NIwS3hRqPxOA==
Application PurposeOriginal Equipment
Application Date2020-09-15
Frequency Range5180-5240 MHz
FRN0022970339
Test FirmSporton International (Kunshan) Inc.
Certified ByJim Tsai Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/14/2021
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2020-09-05
Available2021-03-14
Created2020-09-02
Modified2020-09-02
Pages1
File TypeAdobe Acrobat PDF
File Size123769
File SHA-256c86cbecdfdc082cb31b07f03f221c7de42ef88543bb0dbbcf218814d263affb4
PDF Metadata AuthorWilliam Chen (陳威任)
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 4890735
