FCC ID HDCBSAP2135
Outdoor Wireless Access Point
by Adtran
Grantee Code: HDC Product Code: BSAP2135
Latest application date: 2017-05-15
Device Images
FCC ID Device Details
| FCC ID | HDCBSAP2135 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | HDC |
| Product Code | BSAP2135 |
| Applicant Business | Adtran 🇺🇸 |
| Related Domains |  adtran.com  icertifi.com.tw |
| Equipment Class | Outdoor Wireless Access Point |
| Test Firm | International Certification Corp. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2017-05-15 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2016-03-07 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-03-07 |
| 2412-2462 MHz | Original Equipment | 2015-09-24 |
| 5180-5240 MHz | Original Equipment | 2015-09-24 |
| 2412-2462 MHz | Original Equipment | 2015-09-17 |
| 5180-5240 MHz | Original Equipment | 2015-09-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-03-07 | PDF 92.5 KB |
| Revised User Manuals | Users Manual | 2015-09-24 | PDF 1.4 MB |
| User manual | Users Manual | 2015-09-24 | PDF 841.5 KB |
| User manual (statement) rev | Users Manual | 2015-09-24 | PDF 156.3 KB |
| Users Manual | Users Manual | 2015-09-24 | PDF 845.6 KB |
| User manual rev Metadata only | Users Manual | PDF 156.3 KB | |
| Users Manual (Statement).pdf Metadata only | Users Manual | PDF 513.6 KB | |
| Users Manual.pdf Metadata only | Users Manual | PDF 841.5 KB | |
| Internal photos rev | Internal Photos | 2015-09-24 | PDF 4.4 MB |
| Internal phtos rev | Internal Photos | 2015-09-24 | PDF 4.4 MB |
| Internal Photos_rev.pdf Metadata only | Internal Photos | PDF 4.4 MB | |
| External photos rev | External Photos | 2015-09-24 | PDF 745.3 KB |
| External phtos rev | External Photos | 2015-09-24 | PDF 745.3 KB |
| External Photos_rev.pdf Metadata only | External Photos | PDF 745.3 KB | |
| Label location rev | ID Label/Location Info | 2015-09-24 | PDF 53.5 KB |
| Label sample | ID Label/Location Info | 2015-09-24 | PDF 167.3 KB |
| Labem sample | ID Label/Location Info | 2015-09-24 | PDF 167.3 KB |
| Label Location_rev.pdf Metadata only | ID Label/Location Info | PDF 53.5 KB | |
| Label Sample.PDF Metadata only | ID Label/Location Info | PDF 167.3 KB | |
| Operational description | Operational Description | 2015-09-24 | PDF 37 KB |
| Test setup photo | Test Setup Photos | 2017-05-15 | PDF 185.5 KB |
| Test setup photo_DFS | Test Setup Photos | 2017-05-15 | PDF 240 KB |
| Test Setup Photos | Test Setup Photos | 2016-03-07 | PDF 897.1 KB |
| Test Setup Photos | Test Setup Photos | 2015-09-24 | PDF 310 KB |
| Test setup photo | Test Setup Photos | 2015-09-24 | PDF 293.3 KB |
| Test setup photos | Test Setup Photos | 2015-09-24 | PDF 293.3 KB |
| Test Set Up Photo.pdf Metadata only | Test Setup Photos | PDF 293.3 KB | |
| Test report_15.407 | Test Report | 2017-05-15 | PDF 515.7 KB |
| Test report_DFS | Test Report | 2017-05-15 | PDF 3.1 MB |
| Test Report 2.4ghz | Test Report | 2016-03-07 | PDF 2.3 MB |
| Test Report 5GHz 15.407 Part 1 | Test Report | 2016-03-07 | PDF 5.1 MB |
| Test Report 5GHz 15.407 Part 2 | Test Report | 2016-03-07 | PDF 3.7 MB |
| Revised NII test report | Test Report | 2015-09-24 | PDF 837.8 KB |
| Test Report | Test Report | 2015-09-24 | PDF 794.2 KB |
| Test report (DTS) | Test Report | 2015-09-24 | PDF 1.2 MB |
| Test report (NII) rev Metadata only | Test Report | 2015-09-24 | PDF 1.2 MB |
| Test Report (DTS).pdf Metadata only | Test Report | PDF 1.2 MB | |
| Test Report (NII).pdf Metadata only | Test Report | PDF 697 KB | |
| Professional Installation Attestation | Cover Letter(s) | 2016-03-07 | PDF 31.3 KB |
| Channel and mode declaration | Attestation Statements | 2015-09-24 | PDF 25.4 KB |
| Professional installation declaration | Attestation Statements | 2015-09-24 | PDF 31.3 KB |
| Attestation (Channel and Mode Declaration).pdf Metadata only | Attestation Statements | PDF 25.4 KB | |
| Attestation (Professional Installation Declaration).PDF Metadata only | Attestation Statements | PDF 31.3 KB | |
| C2PC | Cover Letter(s) | 2017-05-15 | PDF 370.9 KB |
| POA | Cover Letter(s) | 2017-05-15 | PDF 414.8 KB |
| PRO_INSTAL | Cover Letter(s) | 2017-05-15 | PDF 320.2 KB |
| confidentiality | Cover Letter(s) | 2017-05-15 | PDF 432.8 KB |
| Class II Permissive Change Letter | Cover Letter(s) | 2016-03-07 | PDF 111.7 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-03-07 | PDF 121.4 KB |
| Cover Letter | Cover Letter(s) | 2016-03-07 | PDF 111.7 KB |
| POA | Cover Letter(s) | 2016-03-07 | PDF 499.3 KB |
| Agent authorization | Cover Letter(s) | 2015-09-24 | PDF 31.3 KB |
| Confidential request rev | Cover Letter(s) | 2015-09-24 | PDF 35.1 KB |
| Response | Cover Letter(s) | 2015-09-24 | PDF 94.5 KB |
| Confidentiality Request_rev.pdf | Cover Letter(s) | PDF 35.1 KB | |
| Cover Letter (Agent Authorization).pdf | Cover Letter(s) | PDF 31.3 KB | |
| Dismiss Request Letter.pdf | Cover Letter(s) | PDF 24.2 KB | |
| MPE | RF Exposure Info | 2017-05-15 | PDF 62.6 KB |
| RF Exposure | RF Exposure Info | 2016-03-07 | PDF 480.4 KB |
| RF expousre (MPE) | RF Exposure Info | 2015-09-24 | PDF 62.2 KB |
| RF expsoure (MPE) | RF Exposure Info | 2015-09-24 | PDF 62.2 KB |
| RF Exposure Info (MPE).pdf Metadata only | RF Exposure Info | PDF 62.2 KB | |
| 2G module Metadata only | Block Diagram | PDF 83.3 KB | |
| 5G module Metadata only | Block Diagram | PDF 86.8 KB | |
| Block Diagram (2G module).pdf Metadata only | Block Diagram | PDF 83.3 KB | |
| Block Diagram (5G module).pdf Metadata only | Block Diagram | PDF 86.8 KB | |
| Block Diagram (System).pdf Metadata only | Block Diagram | PDF 14.6 KB | |
| Block diagram (2G module) Metadata only | Block Diagram | PDF 83.3 KB | |
| Block diagram (5G module) Metadata only | Block Diagram | PDF 86.8 KB | |
| Block system (system) Metadata only | Block Diagram | PDF 14.6 KB | |
| System Metadata only | Block Diagram | PDF 14.6 KB | |
| Schematics (2G module) Metadata only | Schematics | PDF 114.9 KB | |
| Schematics (2G module).pdf Metadata only | Schematics | PDF 114.9 KB | |
| Schematics (5G module) Metadata only | Schematics | PDF 112.1 KB | |
| Schematics (5G module).pdf Metadata only | Schematics | PDF 112.1 KB | |
| Schematics (System) Metadata only | Schematics | PDF 560.2 KB | |
| Schematics (System).pdf Metadata only | Schematics | PDF 560.2 KB | |
| Schmatics (system) Metadata only | Schematics | PDF 560.2 KB | |
| Schmmatics (5G module) Metadata only | Schematics | PDF 112.1 KB | |
| Antenna spec (2.4G) Metadata only | Operational Description | PDF 1,009.6 KB | |
| Antenna spec (5G) 0917 Metadata only | Operational Description | PDF 556 KB | |
| Antenna spec (5G) rev Metadata only | Operational Description | PDF 1.3 MB | |
| Operating Description.pdf Metadata only | Operational Description | PDF 37 KB | |
| Operational Description - Antenna Metadata only | Operational Description | PDF 32.3 KB | |
| Operational Description Antenna Spec. (2.4G).pdf Metadata only | Operational Description | PDF 1,009.6 KB | |
| Operational Description Antenna Spec. (5.0G).pdf Metadata only | Operational Description | PDF 553.3 KB | |
| Operational Description Antenna m5016019d30006i Metadata only | Operational Description | PDF 956.2 KB | |
| Operational Description Antenna m6013070p30006i Metadata only | Operational Description | PDF 256.3 KB | |
| Operational Description Antenna m6060070mp13620 Metadata only | Operational Description | PDF 268.6 KB | |
| Operational Description Software Security Metadata only | Operational Description | PDF 138 KB | |
| SW Security letter Metadata only | Operational Description | PDF 1.3 MB | |
| Software Operatioal description rev Metadata only | Operational Description | PDF 35.3 KB | |
| Software Operational Description_rev.pdf Metadata only | Operational Description | PDF 35.3 KB | |
| Software Operational description rev Metadata only | Operational Description | PDF 35.3 KB |
Application Information
| Application ID | U3AEv5DfhRvpfJsU24kfJg== |
|---|---|
| Final Action Date | 2017-05-15 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0005813993 |
| Model | BSAP2135 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Outdoor Wireless Access Point |
| Responsible Party | Dan Cassidy, Sr Mgr Compliance Engineering, dan.cassidy@adtran.com , 256-963-8186 |
| Agent | Gary Gary Gary, International Certification Corp., GaryChang@icertifi.com.tw , 886-3-271-8628 |
| Technical Contact | Gary Chang, International Certification Corp., GaryChang@icertifi.com.tw , 886-3-271-8628 |
| Non-Technical Contact | Wendy Liao, International Certification Corp., wendyLiao@icertifi.com.tw , 886-3-271-8629 |
| Test Firm | Fu-Cheng Chuang, International Certification Corp., Jeff@icertifi.com.tw , 886-3-271-8666 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Class II Permissive Change: Only firmware setting has been changed to enable U-NII Band 2A and Band 2C. Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 65 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz , 40 MHz and 80 MHz bandwidth mode. Antenna must be installed vertically for outdoor use in 5.15-5.25G band. (Date of Grant: 09/24/2015) |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| U3AEv5DfhRvpfJsU24kfJg== | 2017-05-15 | Class II permissive change or modification of presently authorized equipment |
| k3QcBYmfAimYaVvc/Z6qUQ== | 2016-03-07 | Class II permissive change or modification of presently authorized equipment |
| 6kApSSk220UaJN1Ed8crLw== | 2016-03-07 | Class II permissive change or modification of presently authorized equipment |
| nj/41sdQKjS19topRp9bYw== | 2015-09-24 | Original Equipment |
| lGxXi6d8MFDvACa0l9cmrA== | 2015-09-24 | Original Equipment |
| brKbOuJ7r0XxP1biO378xg== | 2015-09-17 | Original Equipment |
| UIdCT/1aAEn2Sy3x2/Mjdg== | 2015-09-17 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application UIdCT/1aAEn2Sy3x2/Mjdg==
This application does not exist.
EAS Grant - Application UIdCT/1aAEn2Sy3x2/Mjdg==
This application currently is not in final status.
TCB Grant - Application U3AEv5DfhRvpfJsU24kfJg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 05/15/2017 Application Dated: 05/08/2017 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Outdoor Wireless Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.217 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.229 | ||
| 38 CC MO ND | 15E | 5500.0 - 5580.0 | 0.248 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.591 | ||
| 38 CC MO ND | 15E | 5660.0 - 5700.0 | 0.22 |
| Class II Permissive Change: Only firmware setting has been changed to enable U-NII Band 2A and Band 2C. Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 65 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz , 40 MHz and 80 MHz bandwidth mode. Antenna must be installed vertically for outdoor use in 5.15-5.25G band. (Date of Grant: 09/24/2015) |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application U3AEv5DfhRvpfJsU24kfJg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 05/15/2017 Application Dated: 05/08/2017 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Outdoor Wireless Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.217 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.229 | ||
| 38 CC MO ND | 15E | 5500.0 - 5580.0 | 0.248 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.591 | ||
| 38 CC MO ND | 15E | 5660.0 - 5700.0 | 0.22 |
| Class II Permissive Change: Only firmware setting has been changed to enable U-NII Band 2A and Band 2C. Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 65 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz , 40 MHz and 80 MHz bandwidth mode. Antenna must be installed vertically for outdoor use in 5.15-5.25G band. (Date of Grant: 09/24/2015) |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 09/24/2015 Application Dated: 09/18/2015 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Outdoor Wireless Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.247 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application nj/41sdQKjS19topRp9bYw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 09/24/2015 Application Dated: 09/18/2015 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Outdoor Wireless Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.247 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 09/24/2015 Application Dated: 09/18/2015 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Outdoor Wireless Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.217 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.591 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz , 40 MHz and 80 MHz bandwidth mode. Antenna must be installed vertically for outdoor use in 5.15-5.25G band. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application lGxXi6d8MFDvACa0l9cmrA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 09/24/2015 Application Dated: 09/18/2015 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Outdoor Wireless Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.217 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.591 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz , 40 MHz and 80 MHz bandwidth mode. Antenna must be installed vertically for outdoor use in 5.15-5.25G band. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/07/2016 Application Dated: 01/26/2016 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Outdoor Wireless Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.247 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 65 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz and 40 MHz bandwidth mode. (Date of Grant: 09/24/2015) Class II Permissive Change: This Class II Permissive Change is to add the following antennas: Terrawave P/N: M6013070P30006I (2.4/5 GHz 13/7 dBi High Density MIMO Patch Array Antenna); Terrawave P/N: M6060070MP13620 (2.4/5 GHz 6/7 dBi MIMO Patch Antenna); Terrawave P/N: M5016019D30006I (5GHz, 19dBi High Gain, Triple Polarization Directional Antenna). |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application k3QcBYmfAimYaVvc/Z6qUQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 03/07/2016 Application Dated: 01/26/2016 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Outdoor Wireless Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.247 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 65 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz and 40 MHz bandwidth mode. (Date of Grant: 09/24/2015) Class II Permissive Change: This Class II Permissive Change is to add the following antennas: Terrawave P/N: M6013070P30006I (2.4/5 GHz 13/7 dBi High Density MIMO Patch Array Antenna); Terrawave P/N: M6060070MP13620 (2.4/5 GHz 6/7 dBi MIMO Patch Antenna); Terrawave P/N: M5016019D30006I (5GHz, 19dBi High Gain, Triple Polarization Directional Antenna). |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/07/2016 Application Dated: 01/26/2016 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Outdoor Wireless Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.217 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.591 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 65 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz , 40 MHz and 80 MHz bandwidth mode. Antenna must be installed vertically for outdoor use in 5.15-5.25G band. (Date of Grant: 09/24/2015) Class II Permissive Change: This Class II Permissive Change is to add the following antennas: Terrawave P/N: M6013070P30006I (2.4/5 GHz 13/7 dBi High Density MIMO Patch Array Antenna); Terrawave P/N: M6060070MP13620 (2.4/5 GHz 6/7 dBi MIMO Patch Antenna); Terrawave P/N: M5016019D30006I (5GHz, 19dBi High Gain, Triple Polarization Directional Antenna). |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 6kApSSk220UaJN1Ed8crLw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 03/07/2016 Application Dated: 01/26/2016 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCBSAP2135 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Outdoor Wireless Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.217 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.591 |
| Power listed is the maximum combined conducted output power. This device must be professionally installed. Marketing to the General Public is prohibited. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. The use of other antenna requires a Class II Permissive Change filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 65 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz , 40 MHz and 80 MHz bandwidth mode. Antenna must be installed vertically for outdoor use in 5.15-5.25G band. (Date of Grant: 09/24/2015) Class II Permissive Change: This Class II Permissive Change is to add the following antennas: Terrawave P/N: M6013070P30006I (2.4/5 GHz 13/7 dBi High Density MIMO Patch Array Antenna); Terrawave P/N: M6060070MP13620 (2.4/5 GHz 6/7 dBi MIMO Patch Antenna); Terrawave P/N: M5016019D30006I (5GHz, 19dBi High Gain, Triple Polarization Directional Antenna). |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
