TRACERT1L7 Tracer, Rack Mount Teardown... - FCC ID HDCTRACERT1L7
FCC ID HDCTRACERT1L7
Internal and External Photos (24)
Tracer, Rack Mount
by Adtran
Document preview loads when visible.
Document Details
| FCC ID | HDCTRACERT1L7 |
|---|---|
| Document ID | 23690 |
| Document Type | Internal Photos |
| Description | Internal and External Photos (24) |
| Document Title | Tracer Rack Mount Photographs |
| Applicant | Adtran |
| Equipment Class | Tracer, Rack Mount |
| Product Code | TRACERT1L7 |
| Application ID | 5fe2YXJvVRnZnqpfCZcGAg== |
| Application Purpose | Original Equipment |
| Application Date | 1999-04-20 |
| Frequency Range | 2422-2462 MHz |
| FRN | 0005813993 |
| Test Firm | Intertek Testing Services |
| Certified By | David J. Schramm EMC Technical Supervisor |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 1999-02-16 |
| Available | 1999-04-20 |
| Pages | 24 |
| File Type | Adobe Acrobat PDF |
| File Size | 2388896 |
| File SHA-256 | 17f30d73b4cd9b7fc249a2e943d4942e35f389f7805bef7688979d7a7c9cfbe0 |
| PDF Metadata Author | djs |
| PDF Metadata Producer | Microsoft Word Acrobat PDFWriter 3.02 for Windows |
| FCC.gov Sources | FCC.gov 23690 |
