FCC ID HDCWLAN193XF1
Wireless 802.11 abgn PCIe module
by Adtran
Grantee Code: HDC Product Code: WLAN193XF1
Latest application date: 2016-05-12
Device Images
FCC ID Device Details
| FCC ID | HDCWLAN193XF1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | HDC |
| Product Code | WLAN193XF1 |
| Applicant Business | Adtran 🇺🇸 |
| Related Domains |  adtran.com |
| Equipment Class | Wireless 802.11 abgn PCIe module |
| Test Firm | UL Verification Services Inc. (formerly UL CCS) |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-05-12 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2016-01-28 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-10-05 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2013-12-27 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2013-12-27 |
| 5180-5240 MHz | Original Equipment | 2013-01-21 |
| 2412-2462 MHz | Original Equipment | 2013-01-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-01-28 | PDF 92.5 KB |
| User Manual | Users Manual | 2013-01-21 | PDF 107.5 KB |
| Internal Photos.pdf | Internal Photos | 2013-12-27 | PDF 1 MB |
| Internal Photos | Internal Photos | 2013-01-21 | PDF 1 MB |
| External Photos.pdf | External Photos | 2013-12-27 | PDF 1 MB |
| External Photos | External Photos | 2013-01-21 | PDF 3.6 MB |
| Label | ID Label/Location Info | 2013-01-21 | PDF 27.5 KB |
| Label Location | ID Label/Location Info | 2013-01-21 | PDF 123.9 KB |
| Operational Description | Operational Description | 2013-01-21 | PDF 18 KB |
| 14M19448-2A FCC IC UNII WLAN DFS REPORT_Final_Photos Only | Test Setup Photos | 2016-05-12 | PDF 41.9 KB |
| RF121012C11A_TSup photo | Test Setup Photos | 2016-05-12 | PDF 627.5 KB |
| Test Setup Photos | Test Setup Photos | 2016-01-28 | PDF 700.8 KB |
| Test Setup Photos.pdf | Test Setup Photos | 2015-10-05 | PDF 627.5 KB |
| Test Setup Photos.pdf | Test Setup Photos | 2013-12-27 | PDF 222.3 KB |
| Test Setup Photos | Test Setup Photos | 2013-01-21 | PDF 596.5 KB |
| 14M19448-2A FCC IC UNII WLAN DFS REPORT_Final_No Photos | Test Report | 2016-05-12 | PDF 1.1 MB |
| RF121012C11A_Senao_BSAP-1930_FCC 15.407 | Test Report | 2016-05-12 | PDF 658.1 KB |
| RF121012C11B_Senao_BSAP-1930_FCC 15.407)_Rev 1 | Test Report | 2016-05-12 | PDF 1 MB |
| Test Report | Test Report | 2016-01-28 | PDF 1.4 MB |
| Test Report_rev.pdf | Test Report | 2015-10-05 | PDF 658.1 KB |
| Test Report (Co located).pdf | Test Report | 2013-12-27 | PDF 304.7 KB |
| Test Report (DTS).pdf | Test Report | 2013-12-27 | PDF 304.3 KB |
| Test Report (NII).pdf | Test Report | 2013-12-27 | PDF 631.7 KB |
| Test Report - 15C | Test Report | 2013-01-21 | PDF 3.2 MB |
| Test Report - 15E | Test Report | 2013-01-21 | PDF 583.6 KB |
| Attestation - Channel and Mode Declaration | Attestation Statements | 2013-01-21 | PDF 56.3 KB |
| C2PC_BASP-1930 | Cover Letter(s) | 2016-05-12 | PDF 39.4 KB |
| FCC EQUIP AUTH | Cover Letter(s) | 2016-05-12 | PDF 1.1 MB |
| FCC_Confi_HDCWLAN193XF1 (1) | Cover Letter(s) | 2016-05-12 | PDF 521.8 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-01-28 | PDF 119.5 KB |
| Cover Letter | Cover Letter(s) | 2016-01-28 | PDF 113.3 KB |
| POA | Cover Letter(s) | 2016-01-28 | PDF 499.3 KB |
| Confidentiality Request.PDF | Cover Letter(s) | 2015-10-05 | PDF 450.7 KB |
| Cover Letter (Agent Authorization).PDF | Cover Letter(s) | 2015-10-05 | PDF 396.1 KB |
| Cover Letter (Description of Change).pdf | Cover Letter(s) | 2015-10-05 | PDF 10.5 KB |
| Cover Letter (Agent Authorization).pdf | Cover Letter(s) | 2013-12-27 | PDF 66.5 KB |
| Cover Letter (Description of Change).pdf | Cover Letter(s) | 2013-12-27 | PDF 10 KB |
| Confidentiality Request | Cover Letter(s) | 2013-01-21 | PDF 47.9 KB |
| Cover Letter - Agent Authorization | Cover Letter(s) | 2013-01-21 | PDF 52 KB |
| Cover Letter - Modular Approval Request | Cover Letter(s) | 2013-01-21 | PDF 44.9 KB |
| SA121012C11A_Senao_BSAP-1930_FCC MPE | RF Exposure Info | 2016-05-12 | PDF 60.9 KB |
| SA121012C11B_Senao_BSAP-1930_FCC MPE | RF Exposure Info | 2016-05-12 | PDF 122.5 KB |
| RF Exposure | RF Exposure Info | 2016-01-28 | PDF 397.3 KB |
| RF Exposure Info (MPE).pdf | RF Exposure Info | 2015-10-05 | PDF 60.9 KB |
| RF Exposure Info (MPE).pdf | RF Exposure Info | 2013-12-27 | PDF 46.1 KB |
| RF Exposure Info | RF Exposure Info | 2013-01-21 | PDF 73.9 KB |
| BSAP-1930 SCHEMATIC-2015-06-04 Metadata only | Schematics | PDF 554.5 KB | |
| Operational Description Antenna Specification Metadata only | Operational Description | PDF 256.3 KB | |
| Operational Description Software Security Metadata only | Operational Description | PDF 127.8 KB | |
| Software Operating Description.pdf Metadata only | Operational Description | PDF 166.8 KB | |
| Software Operational Description FCC_1930 Metadata only | SDR Software/Security Inf | PDF 157.3 KB | |
| bsap 1930 FCC Device SW Security Statement Metadata only | Operational Description | PDF 190.5 KB |
Application Information
| Application ID | pu8CjDlLkMcfxmfnOnTB0w== |
|---|---|
| Final Action Date | 2016-05-12 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0005813993 |
| Model | WLAN193XF1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless 802.11 abgn PCIe module |
| Responsible Party | Dan Cassidy, Sr Mgr Compliance Engineering, dan.cassidy@adtran.com , 256-963-8186 |
| Test Firm | Jay Kogoma, UL Verification Services Inc. (formerly UL CCS), jay.kogoma@ul.com  , 510-319-4135 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Class II Permissive Change to add U-NII-2A and U-NI-2C bands with the new rules for U-NII devices adopted under Docket No. 13-49. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| pu8CjDlLkMcfxmfnOnTB0w== | 2016-05-12 | Class II permissive change or modification of presently authorized equipment |
| gHcmEUXcderXGvxnyDLuUw== | 2016-01-28 | Class II permissive change or modification of presently authorized equipment |
| JXM73Z5Xwx+o1Y1ofT02bg== | 2015-10-05 | Class II permissive change or modification of presently authorized equipment |
| qsIWW2kTVacJrnnMkUqCHA== | 2013-12-27 | Class II permissive change or modification of presently authorized equipment |
| RrH3TzxhM4d34Xe1xQt1NA== | 2013-12-27 | Class II permissive change or modification of presently authorized equipment |
| h6yewBa/xgzc5UAfaUs2Dw== | 2013-01-21 | Original Equipment |
| cU9GSXLj4jGFw2oOpGIkzQ== | 2013-01-21 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application RrH3TzxhM4d34Xe1xQt1NA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 12/27/2013 Application Dated: 12/27/2013 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn AP |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.026 |
| Class II Permissive Change as described in this filing. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application RrH3TzxhM4d34Xe1xQt1NA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 12/27/2013 Application Dated: 12/27/2013 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn AP |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.026 |
| Class II Permissive Change as described in this filing. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 12/27/2013 Application Dated: 12/27/2013 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless 802.11 abgn AP |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.241 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.144 |
| Class II Permissive Change as described in this filing. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application qsIWW2kTVacJrnnMkUqCHA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 12/27/2013 Application Dated: 12/27/2013 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless 802.11 abgn AP |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.241 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.144 |
| Class II Permissive Change as described in this filing. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 05/12/2016 Application Dated: 04/22/2016 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn PCIe module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.223 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.179 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.087 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.136 |
| Class II Permissive Change to add U-NII-2A and U-NI-2C bands with the new rules for U-NII devices adopted under Docket No. 13-49. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application pu8CjDlLkMcfxmfnOnTB0w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 05/12/2016 Application Dated: 04/22/2016 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn PCIe module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.223 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.179 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.087 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.136 |
| Class II Permissive Change to add U-NII-2A and U-NI-2C bands with the new rules for U-NII devices adopted under Docket No. 13-49. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 10/05/2015 Application Dated: 10/05/2015 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn AP |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.223 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.136 |
| Class II Permissive Change to update 5GHz band to U-NII band new rule. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application JXM73Z5Xwx+o1Y1ofT02bg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 10/05/2015 Application Dated: 10/05/2015 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn AP |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.223 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.136 |
| Class II Permissive Change to update 5GHz band to U-NII band new rule. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 01/21/2013 Application Dated: 01/21/2013 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn PCIe module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.026 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application h6yewBa/xgzc5UAfaUs2Dw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 01/21/2013 Application Dated: 01/21/2013 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless 802.11 abgn PCIe module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.026 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 01/28/2016 Application Dated: 01/28/2016 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless 802.11 abgn AP |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.241 |
| Class II Permissive Change as described in this filing. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 35cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application gHcmEUXcderXGvxnyDLuUw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 01/28/2016 Application Dated: 01/28/2016 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless 802.11 abgn AP |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.241 |
| Class II Permissive Change as described in this filing. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 35cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 01/21/2013 Application Dated: 01/21/2013 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless 802.11 abgn PCIe module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.241 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.144 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application cU9GSXLj4jGFw2oOpGIkzQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 01/21/2013 Application Dated: 01/21/2013 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN193XF1 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless 802.11 abgn PCIe module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.241 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.144 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
