FCC ID HDCWLAN194XF2
802.11 an PCIe Module
by Adtran
Grantee Code: HDC Product Code: WLAN194XF2
Latest application date: 2016-05-12
Device Images
FCC ID Device Details
| FCC ID | HDCWLAN194XF2 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | HDC |
| Product Code | WLAN194XF2 |
| Applicant Business | Adtran 🇺🇸 |
| Related Domains |  adtran.com |
| Equipment Class | 802.11 an PCIe Module |
| Test Firm | UL Verification Services Inc. (formerly UL CCS) |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-05-12 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-10-01 |
| 5180-5240 MHz | Original Equipment | 2013-02-07 |
| 5745-5825 MHz | Original Equipment | 2013-02-07 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual_rev.pdf | Users Manual | 2015-10-01 | PDF 966.3 KB |
| User manual | Users Manual | 2013-02-07 | PDF 137.2 KB |
| internal photo | Internal Photos | 2013-02-07 | PDF 281.1 KB |
| External photo | External Photos | 2013-02-07 | PDF 533.5 KB |
| label info | ID Label/Location Info | 2013-02-07 | PDF 109 KB |
| 14M19445-2A FCC IC UNII WLAN DFS REPORT_Final_Photos Only | Test Setup Photos | 2016-05-12 | PDF 43.2 KB |
| RF150804C20A_TSup photo_rev | Test Setup Photos | 2016-05-12 | PDF 339.9 KB |
| RF150804C20_TSup photo | Test Setup Photos | 2016-05-12 | PDF 288.4 KB |
| Test Setup Photos.pdf | Test Setup Photos | 2015-10-01 | PDF 288.4 KB |
| test setup photo | Test Setup Photos | 2013-02-07 | PDF 419.6 KB |
| 14M19445-2A FCC IC UNII WLAN DFS REPORT_Final_No Photos | Test Report | 2016-05-12 | PDF 1.1 MB |
| RF150804C20A_Adtran_WLAN194XF2_15.407_rev | Test Report | 2016-05-12 | PDF 584 KB |
| RF150804C20_Adtran_WLAN194XF2_15.407 | Test Report | 2016-05-12 | PDF 484.5 KB |
| Test Report.pdf | Test Report | 2015-10-01 | PDF 484.5 KB |
| test report | Test Report | 2013-02-07 | PDF 1.3 MB |
| test report | Test Report | 2013-02-07 | PDF 1.2 MB |
| 15B DoC letter | Attestation Statements | 2013-02-07 | PDF 58.1 KB |
| C2PC_BSAP-1940 | Cover Letter(s) | 2016-05-12 | PDF 318.2 KB |
| FCC EQUIP AUTH | Cover Letter(s) | 2016-05-12 | PDF 1.1 MB |
| FCC_Confi_HDCWLAN194XF1_2250A-WLAN194XF2 (1) | Cover Letter(s) | 2016-05-12 | PDF 524.1 KB |
| Confidentiality Request.PDF | Cover Letter(s) | 2015-10-01 | PDF 450.7 KB |
| Cover Letter (Agent Authorization).PDF | Cover Letter(s) | 2015-10-01 | PDF 396.4 KB |
| Cover Letter (Description of Change).pdf | Cover Letter(s) | 2015-10-01 | PDF 10.5 KB |
| POA | Cover Letter(s) | 2013-02-07 | PDF 58.7 KB |
| confidential request letter | Cover Letter(s) | 2013-02-07 | PDF 58.8 KB |
| module request letter | Cover Letter(s) | 2013-02-07 | PDF 17.8 KB |
| SA150804C20A_Adtran_WLAN194XF2_FCC MPE | RF Exposure Info | 2016-05-12 | PDF 56.2 KB |
| SA150804C20_Adtran_WLAN194XF2_FCC MPE | RF Exposure Info | 2016-05-12 | PDF 55.9 KB |
| RF Exposure Info (MPE).pdf | RF Exposure Info | 2015-10-01 | PDF 55.9 KB |
| MPE | RF Exposure Info | 2013-02-07 | PDF 127.9 KB |
| BSAP 1940 FCC SW Security Statement Metadata only | Operational Description | PDF 190.9 KB | |
| Software Operating Description_rev.pdf Metadata only | Operational Description | PDF 167.2 KB | |
| Software Operational Description FCC_1940 Metadata only | SDR Software/Security Inf | PDF 159.4 KB |
Application Information
| Application ID | yK2SDGUO2/vlzxlZz6uGcA== |
|---|---|
| Final Action Date | 2016-05-12 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0005813993 |
| Model | WLAN194XF2 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | 802.11 an PCIe Module |
| Responsible Party | Dan Cassidy, Sr Mgr Compliance Engineering, dan.cassidy@adtran.com , 256-963-8186 |
| Test Firm | Jay Kogoma, UL Verification Services Inc. (formerly UL CCS), jay.kogoma@ul.com  , 510-319-4135 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Class II Permissive Change to add U-NII-2A and U-NI-2C bands with the new rules for U-NII devices adopted under Docket No. 13-49. Output power listed is conducted. Single Modular Approval. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna(s) used for this transmitter must be installed as described in this filing, and must not be co-located or operate in conjunction with any other antenna or transmitter except as documented in filings under this FCC ID and/or in accordance with FCC multi-transmitter product guidelines. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| yK2SDGUO2/vlzxlZz6uGcA== | 2016-05-12 | Class II permissive change or modification of presently authorized equipment |
| VbpHUJFZPmz+uwGbtH065A== | 2015-10-01 | Class II permissive change or modification of presently authorized equipment |
| vDhLAY28WYmaAzAgk9sIng== | 2013-02-07 | Original Equipment |
| gPOYhUE0ETWBNd9VHKO2VA== | 2013-02-07 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application yK2SDGUO2/vlzxlZz6uGcA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 05/12/2016 Application Dated: 04/22/2016 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.303 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.121 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.149 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.224 |
| Class II Permissive Change to add U-NII-2A and U-NI-2C bands with the new rules for U-NII devices adopted under Docket No. 13-49. Output power listed is conducted. Single Modular Approval. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna(s) used for this transmitter must be installed as described in this filing, and must not be co-located or operate in conjunction with any other antenna or transmitter except as documented in filings under this FCC ID and/or in accordance with FCC multi-transmitter product guidelines. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application yK2SDGUO2/vlzxlZz6uGcA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 05/12/2016 Application Dated: 04/22/2016 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.303 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.121 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.149 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.224 |
| Class II Permissive Change to add U-NII-2A and U-NI-2C bands with the new rules for U-NII devices adopted under Docket No. 13-49. Output power listed is conducted. Single Modular Approval. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna(s) used for this transmitter must be installed as described in this filing, and must not be co-located or operate in conjunction with any other antenna or transmitter except as documented in filings under this FCC ID and/or in accordance with FCC multi-transmitter product guidelines. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 02/07/2013 Application Dated: 02/07/2013 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.0324 | ||
| CC MO | 15E | 5190.0 - 5230.0 | 0.0395 |
| Output Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Operating of this device in the 5150 MHz to 5250 MHz range is restricted to indoor use only. Device is operating in a 3T3R Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application vDhLAY28WYmaAzAgk9sIng==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 02/07/2013 Application Dated: 02/07/2013 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.0324 | ||
| CC MO | 15E | 5190.0 - 5230.0 | 0.0395 |
| Output Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Operating of this device in the 5150 MHz to 5250 MHz range is restricted to indoor use only. Device is operating in a 3T3R Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 10/01/2015 Application Dated: 10/01/2015 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.303 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.224 |
| Class II Permissive Change to update 5GHz bands to U-NII new rule. Output power listed is conducted. Single Modular Approval. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna(s) used for this transmitter must be installed as described in this filing, and must not be co-located or operate in conjunction with any other antenna or transmitter except as documented in filings under this FCC ID and/or in accordance with FCC multi-transmitter product guidelines. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application VbpHUJFZPmz+uwGbtH065A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 10/01/2015 Application Dated: 10/01/2015 |
| Attention: Dan Cassidy , Sr Mgr Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.303 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.224 |
| Class II Permissive Change to update 5GHz bands to U-NII new rule. Output power listed is conducted. Single Modular Approval. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna(s) used for this transmitter must be installed as described in this filing, and must not be co-located or operate in conjunction with any other antenna or transmitter except as documented in filings under this FCC ID and/or in accordance with FCC multi-transmitter product guidelines. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 02/07/2013 Application Dated: 02/06/2013 |
| Adtran |
| 901 Explorer Boulevard |
| Huntsville, AL 35806-2807 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 5745.0 - 5825.0 | 0.6012 | ||
| CC MO | 15C | 5755.0 - 5795.0 | 0.5834 |
| Output Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Device is operating in a 3T3R Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5755 to 5795 MHz. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application gPOYhUE0ETWBNd9VHKO2VA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Adtran 901 Explorer Boulevard Huntsville, AL 35806-2807 United States |
Date of Grant: 02/07/2013 Application Dated: 02/06/2013 |
| Attention: Jeff Whitmire , Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HDCWLAN194XF2 |
| Name of Grantee: | Adtran |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11 an PCIe Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 5745.0 - 5825.0 | 0.6012 | ||
| CC MO | 15C | 5755.0 - 5795.0 | 0.5834 |
| Output Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Device is operating in a 3T3R Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5755 to 5795 MHz. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
