FCC ID HED-ML60MDSB
Metrolinq 60 GHz Module
by Accton Technology Corp
Grantee Code: HED Product Code: ML60MDSB
Latest application date: 2019-11-05
Device Images
FCC ID Device Details
| FCC ID | HED-ML60MDSB |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | HED |
| Product Code | ML60MDSB |
| Applicant Business | Accton Technology Corp 🇹🇼 |
| Related Domains |  accton.com |
| Equipment Class | Metrolinq 60 GHz Module |
| Test Firm | Sporton International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 58320-65880 MHz | Class II permissive change or modification of presently authorized equipment | 2019-11-05 |
| 58320-64800 MHz | Class II permissive change or modification of presently authorized equipment | 2018-07-10 |
| 58320-62640 MHz | Class II permissive change or modification of presently authorized equipment | 2016-09-23 |
| 58320-62640 MHz | Original Equipment | 2016-05-05 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2018-07-10 | PDF 455.5 KB |
| User Manual | Users Manual | 2016-09-23 | PDF 668.7 KB |
| Users Manual | Users Manual | 2016-05-05 | PDF 670.9 KB |
| Internal Photos | Internal Photos | 2016-09-23 | PDF 670.1 KB |
| Internal Photos | Internal Photos | 2016-05-05 | PDF 483.6 KB |
| External Photo | External Photos | 2016-09-23 | PDF 314.7 KB |
| External Photos | External Photos | 2016-05-05 | PDF 286.8 KB |
| Label and Location | ID Label/Location Info | 2016-09-23 | PDF 79.1 KB |
| Label and Label Location | ID Label/Location Info | 2016-05-05 | PDF 78.9 KB |
| Test Setup Photos | Test Setup Photos | 2019-11-05 | PDF 286.7 KB |
| Test Setup Photos | Test Setup Photos | 2018-07-10 | PDF 354.7 KB |
| Test Photo | Test Setup Photos | 2016-09-23 | PDF 209.3 KB |
| Test Setup Photos | Test Setup Photos | 2016-05-05 | PDF 536.5 KB |
| MPE Test Report | RF Exposure Info | 2019-11-05 | PDF 297.6 KB |
| Test Report | Test Report | 2019-11-05 | PDF 1.3 MB |
| Test Report | Test Report | 2018-07-10 | PDF 464 KB |
| MPE Test Report | RF Exposure Info | 2016-09-23 | PDF 291.8 KB |
| RF Test Report | RF Exposure Info | 2016-09-23 | PDF 1.8 MB |
| MPE Test Report | RF Exposure Info | 2016-05-05 | PDF 295.3 KB |
| Test Report | Test Report | 2016-05-05 | PDF 1.6 MB |
| C2PC Cover Letter | Cover Letter(s) | 2019-11-05 | PDF 24 KB |
| Confidential Request Letter | Cover Letter(s) | 2019-11-05 | PDF 49.1 KB |
| POA | Cover Letter(s) | 2019-11-05 | PDF 23.3 KB |
| C2PC Letter | Cover Letter(s) | 2018-07-10 | PDF 49.7 KB |
| Modular Approval Letter | Cover Letter(s) | 2018-07-10 | PDF 27.3 KB |
| POA | Cover Letter(s) | 2018-07-10 | PDF 41.4 KB |
| C2PC Letter | Cover Letter(s) | 2016-09-23 | PDF 259.7 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-09-23 | PDF 17 KB |
| POA | Cover Letter(s) | 2016-09-23 | PDF 244.6 KB |
| Agency Authorization Letter | Cover Letter(s) | 2016-05-05 | PDF 174.1 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-05-05 | PDF 170.6 KB |
| Limited Modular Approval Letter | Cover Letter(s) | 2016-05-05 | PDF 27 KB |
| POA | Cover Letter(s) | 2016-05-05 | PDF 143.7 KB |
| MPE Report | RF Exposure Info | 2018-07-10 | PDF 257.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 52.3 KB | |
| Schematics Metadata only | Schematics | PDF 169.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 80.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 81.1 KB |
Application Information
| Application ID | S/XoBsfjImsx5Jqd0YSE/g== |
|---|---|
| Final Action Date | 2019-11-05 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0005033246 |
| Model | ML60MDSB |
| Frequency Range | 58320-65880 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Metrolinq 60 GHz Module |
| Responsible Party | Abby Wei, Manager, mike_peng@accton.com , 886-3-577-0270 |
| Test Firm | Alex CHEN, Sporton International Inc., alex@sporton.com.tw  , +886-3-327-3456 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is conducted. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 57 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 42 dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. Class II Permissive Change: Adds 1.08 GHz and 2.16 GHz channels via software revision. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| S/XoBsfjImsx5Jqd0YSE/g== | 2019-11-05 | Class II permissive change or modification of presently authorized equipment |
| QUXMX7BmNX4xITWslls8uQ== | 2018-07-10 | Class II permissive change or modification of presently authorized equipment |
| vsq6Llf1NpSkJ/W10ripeg== | 2016-09-23 | Class II permissive change or modification of presently authorized equipment |
| WycqBzlHp8n3jBm/WktXkA== | 2016-05-05 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application WycqBzlHp8n3jBm/WktXkA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 05/05/2016 Application Dated: 05/04/2016 |
| Accton Technology Corp |
| No. 1, Creation Rd. III, |
| Science-based Industrial Park |
| Hsin Chu 30077, Taiwan |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60 GHz Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 62640.0 | 0.024 |
| Limited Single Modular Approval. Power listed is conducted. This module is approved for use when installed in Brand: IgniteNet / Model: ML-60-35, ML-60-35-1, ML-60-19, ML-60-19-1. Highest average EIRP with 42 dBi antenna described in the application is 38.11 W. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 56 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
EAS Grant - Application WycqBzlHp8n3jBm/WktXkA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Accton Technology Corp No. 1, Creation Rd. III, Science-based Industrial Park Hsin Chu 30077, Taiwan |
Date of Grant: 05/05/2016 Application Dated: 05/04/2016 |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60 GHz Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 62640.0 | 0.024 |
| Limited Single Modular Approval. Power listed is conducted. This module is approved for use when installed in Brand: IgniteNet / Model: ML-60-35, ML-60-35-1, ML-60-19, ML-60-19-1. Highest average EIRP with 42 dBi antenna described in the application is 38.11 W. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 56 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/23/2016 Application Dated: 09/22/2016 |
| Accton Technology Corp |
| No. 1, Creation Rd. III, |
| Science-based Industrial Park |
| Hsin Chu 30077, Taiwan |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60 GHz Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 62640.0 | 0.024 |
| Single Modular Approval. Power listed is conducted. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 26 dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application vsq6Llf1NpSkJ/W10ripeg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Accton Technology Corp No. 1, Creation Rd. III, Science-based Industrial Park Hsin Chu 30077, Taiwan |
Date of Grant: 09/23/2016 Application Dated: 09/22/2016 |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60 GHz Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 62640.0 | 0.024 |
| Single Modular Approval. Power listed is conducted. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 26 dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 11/05/2019 Application Dated: 11/04/2019 |
| Accton Technology Corp |
| No. 1, Creation Rd. III, |
| Science-based Industrial Park |
| Hsin Chu 30077, Taiwan |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60 GHz Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 65880.0 | 0.024 |
| Single Modular Approval. Power listed is conducted. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 57 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 42 dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. Class II Permissive Change: Adds 1.08 GHz and 2.16 GHz channels via software revision. |
EAS Grant - Application S/XoBsfjImsx5Jqd0YSE/g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Accton Technology Corp No. 1, Creation Rd. III, Science-based Industrial Park Hsin Chu 30077, Taiwan |
Date of Grant: 11/05/2019 Application Dated: 11/04/2019 |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60 GHz Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 65880.0 | 0.024 |
| Single Modular Approval. Power listed is conducted. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 57 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 42 dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. Class II Permissive Change: Adds 1.08 GHz and 2.16 GHz channels via software revision. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/10/2018 Application Dated: 07/09/2018 |
| Accton Technology Corp |
| No. 1, Creation Rd. III, |
| Science-based Industrial Park |
| Hsin Chu 30077, Taiwan |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60GHz Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 64800.0 | 0.024 |
| Single Modular Approval. Power listed is conducted. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 56 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 42 dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application QUXMX7BmNX4xITWslls8uQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Accton Technology Corp No. 1, Creation Rd. III, Science-based Industrial Park Hsin Chu 30077, Taiwan |
Date of Grant: 07/10/2018 Application Dated: 07/09/2018 |
| Attention: Abby Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HED-ML60MDSB |
| Name of Grantee: | Accton Technology Corp |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Metrolinq 60GHz Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 58320.0 - 64800.0 | 0.024 |
| Single Modular Approval. Power listed is conducted. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 56 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 42 dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| Mail To: |
