2555WAG2 Dual Band Access Point Teardown... - FCC ID HED2555WAG2

FCC ID HED2555WAG2

Internal Photo

Dual Band Access Point

by Accton Technology Corp

Document preview loads when visible.

Document Details

FCC IDHED2555WAG2
Document ID637037
Document TypeInternal Photos
DescriptionInternal Photo
Document Titleuntitled
ApplicantAccton Technology Corp
Equipment ClassDual Band Access Point
Product Code2555WAG2
Application IDR7bhGykXtb1RfpwKJD3rpw==
Application PurposeOriginal Equipment
Application Date2006-03-16
Frequency Range5180-5250 MHz
FRN0005033246
Test FirmSporton International Inc.
Certified ByWayne Hsu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2006-03-16
Available2006-03-16
Created2006-02-24
Modified2006-02-24
Pages5
File TypeAdobe Acrobat PDF
File Size274111
File SHA-25688c4f9eaf05edf0bc68f6852607a91f7531e1c142883b37c4c8d7f6ebe0dee7c
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 637037, FCC.gov 636998
