FCC ID HLZDMZ630S
Smart HandHeld
by Acer Incorporated
Grantee Code: HLZ Product Code: DMZ630S
Latest application date: 2015-10-20
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-10-20 |
| 2402-2480 MHz | Original Equipment | 2015-10-20 |
| 699.7-715.3 MHz | Original Equipment | 2015-10-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2016-04-17 | PDF 851.5 KB |
| Int | Internal Photos | 2016-04-17 | PDF 2.4 MB |
| Ext | External Photos | 2016-04-17 | PDF 804.7 KB |
| Location | External Photos | 2015-10-20 | PDF 89.8 KB |
| Location | ID Label/Location Info | 2015-10-20 | PDF 89.8 KB |
| Sample | ID Label/Location Info | 2015-10-20 | PDF 87.8 KB |
| GSM WCDMA | Test Setup Photos | 2016-04-17 | PDF 1.3 MB |
| LTE | Test Setup Photos | 2016-04-17 | PDF 781.1 KB |
| SAR | Test Setup Photos | 2016-04-17 | PDF 536.5 KB |
| Setup | Test Setup Photos | 2016-04-17 | PDF 559.2 KB |
| BLE | Test Setup Photos | 2015-10-20 | PDF 559.2 KB |
| WLAN | Test Setup Photos | 2015-10-20 | PDF 971.8 KB |
| DSS | Test Report | 2015-10-20 | PDF 1.1 MB |
| DTS BT | Test Report | 2015-10-20 | PDF 694.6 KB |
| DTS WLAN | Test Report | 2015-10-20 | PDF 4.9 MB |
| DTS WiFi | Test Report | 2015-10-20 | PDF 213.7 KB |
| PCE GSM WCDMA | Test Report | 2015-10-20 | PDF 4 MB |
| PCE LTE | Test Report | 2015-10-20 | PDF 2.4 MB |
| PCE LTE 1 | Test Report | 2015-10-20 | PDF 5.8 MB |
| PCE LTE 2 | Test Report | 2015-10-20 | PDF 5.8 MB |
| PCE LTE 3 | Test Report | 2015-10-20 | PDF 5.8 MB |
| SAR Data Attestation | RF Exposure Info | 2015-10-20 | PDF 276 KB |
| Authorization | Cover Letter(s) | 2015-10-20 | PDF 237.1 KB |
| Confid | Cover Letter(s) | 2015-10-20 | PDF 158.8 KB |
| Declaration of Reuse | Cover Letter(s) | 2015-10-20 | PDF 276 KB |
| DofC | Cover Letter(s) | 2015-10-20 | PDF 142.4 KB |
| POA | Cover Letter(s) | 2015-10-20 | PDF 222.8 KB |
| Declaration | RF Exposure Info | 2015-10-20 | PDF 276 KB |
| RFx | RF Exposure Info | 2015-10-20 | PDF 102.2 KB |
| SAR | RF Exposure Info | 2015-10-20 | PDF 102.2 KB |
| SAR A B | RF Exposure Info | 2015-10-20 | PDF 3.1 MB |
| SAR C1 | RF Exposure Info | 2015-10-20 | PDF 4 MB |
| SAR C2 | RF Exposure Info | 2015-10-20 | PDF 3.6 MB |
| Variant | RF Exposure Info | 2015-10-20 | PDF 102.2 KB |
| Block Metadata only | Block Diagram | PDF 33.9 KB | |
| Schema Metadata only | Schematics | PDF 3.4 MB | |
| Ant WLAN Metadata only | Operational Description | PDF 169.3 KB | |
| Ant WWAN Metadata only | Operational Description | PDF 362.6 KB | |
| Ops Metadata only | Operational Description | PDF 146.9 KB | |
| Parts Metadata only | Parts List/Tune Up Info | PDF 61.5 KB | |
| Tune Up Metadata only | Parts List/Tune Up Info | PDF 64.9 KB |
Application Information
| Application ID | zel7Eg5LQIOcjrYZqL0TsQ== |
|---|---|
| Final Action Date | 2015-10-20 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013355508 |
| Model | DMZ630S |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Smart HandHeld |
| Responsible Party | Harriot S.L. Lee, Manager, Harriot.Lee@acer.com  , 886-2-6606-3131 |
| Technical Contact | Jones Tsai, Sporton International, jonestsai@sporton.com.tw  , (886)33273456 |
| Test Firm | Alex Chen, Sporton International Inc., alex@sporton.com.tw , 886-3-327-3456 |
| TCB Email | certification@micomlabs.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 04/17/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is Conducted. This device may transmit simultaneously with other Licensed and Unlicensed transmitters. End-users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| zel7Eg5LQIOcjrYZqL0TsQ== | 2015-10-20 | Original Equipment |
| HL3dFSRRHtzts7PBt5nipg== | 2015-10-20 | Original Equipment |
| A1W4vwu48yQFklkjpOcK7g== | 2015-10-20 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 699.7-715.3 MHz | 0.0516 | 0.017ppm | 1M10W7D | 27 | BC |
| 704-711 MHz | 0.0577 | 0.017ppm | 9M13G7D | 27 | BC |
| 704-711 MHz | 0.0509 | 0.017ppm | 9M07W7D | 27 | BC |
| 826.4-846.6 MHz | 0.1113 | 0.062ppm | 4M21F9W | 22H | BC |
| 1710.7-1754.3 MHz | 0.241 | 0.006ppm | 1M10G7D | 27 | BC |
| 1711.5-1753.5 MHz | 0.1986 | 0.006ppm | 2M72W7D | 27 | BC |
| 1712.4-1752.6 MHz | 0.186 | 0.026ppm | 4M21F9W | 27 | BC |
| 1720-1745 MHz | 0.1679 | 0.006ppm | 18M6G7D | 27 | BC |
| 1720-1745 MHz | 0.1507 | 0.006ppm | 18M6W7D | 27 | BC |
| 1850.2-1909.8 MHz | 1.2931 | 0.025ppm | 246KGXW | 24E | BC |
| 1850.2-1909.8 MHz | 0.7104 | 0.024ppm | 247KG7W | 24E | BC |
| 1852.4-1907.6 MHz | 0.178 | 0.026ppm | 4M21F9W | 24E | BC |
| 1860-1900 MHz | 0.33 | 0.028ppm | 18M4G7D | 24E | BC |
| 1860-1900 MHz | 0.3055 | 0.028ppm | 18M5W7D | 24E | BC |
| 2402-2480 MHz | 0.0065000 | 15C | CC | ||
| 2402-2480 MHz | 0.0012 | 15C | CC | ||
| 2412-2462 MHz | 0.0865 | 15C | CC | ||
| 2422-2452 MHz | 0.0893 | 15C | CC | ||
| 2502.5-2567.5 MHz | 0.1841 | 0.024ppm | 4M15W7D | 27 | BC |
| 2505-2565 MHz | 0.2037 | 0.024ppm | 9M11G7D | 27 | BC |
| 2510-2560 MHz | 0.1754 | 0.024ppm | 18M5G7D | 27 | BC |
| 2510-2560 MHz | 0.1524 | 0.024ppm | 18M5W7D | 27 | BC |
Grants
TCB Grant - Application zel7Eg5LQIOcjrYZqL0TsQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
MiCOM Labs 575 Boulder Court Pleasanton, CA 94566 |
Date of Grant: 10/20/2015 Application Dated: 10/20/2015 |
| Acer Incorporated |
| 9F, 88, Sec. 1, Xintai 5th Rd. |
| New Taipei City, 221 Taiwan |
| Attention: Harriot Lee , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HLZDMZ630S |
| Name of Grantee: | Acer Incorporated |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Smart HandHeld |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0065 |
| Power Output listed is Conducted. This device may transmit simultaneously with other Licensed and Unlicensed transmitters. End-users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
