FCC ID HS9-TH6220WF01
Thermostat
by Ademco Inc
Grantee Code: HS9 Product Code: TH6220WF01
Latest application date: 2021-10-29
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2021-10-29 |
| 2412-2462 MHz | Original Equipment | 2016-07-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 33-00392EFS_A- manual-TH6220WF2006_Part1 | Users Manual | 2022-04-27 | PDF 4.6 MB |
| 33-00392EFS_A- manual-TH6220WF2006_Part2 | Users Manual | 2022-04-27 | PDF 4.2 MB |
| User Manual | Users Manual | 2016-11-27 | PDF 1.3 MB |
| user manual | Users Manual | 2016-11-27 | PDF 5.4 MB |
| Internal Photos_20211001_v1 - Internal_photos-TH6220WF2006 | Internal Photos | 2022-04-27 | PDF 928 KB |
| Internal photos | Internal Photos | 2016-11-27 | PDF 928 KB |
| External_Photos_PMVA | External Photos | 2021-10-29 | PDF 265.5 KB |
| External_photos_CAP | External Photos | 2021-10-29 | PDF 203.5 KB |
| External Photos | External Photos | 2016-11-27 | PDF 493.3 KB |
| R32348639_B-Label updated | ID Label/Location Info | 2021-10-29 | PDF 400.6 KB |
| TH6220WF2006 OS label | ID Label/Location Info | 2021-10-29 | PDF 168.8 KB |
| TH6220WF2006-Label location | ID Label/Location Info | 2021-10-29 | PDF 107.3 KB |
| ID Label | ID Label/Location Info | 2016-07-06 | PDF 659.3 KB |
| Antenna info | Operational Description | 2016-07-06 | PDF 112.6 KB |
| R13708588-E3 v2 15.247 RSS-247 2.4 GHz WLAN Spotcheck Setup photos | Test Setup Photos | 2022-04-27 | PDF 1.4 MB |
| R13708588-EP1 v2 FCC 15.247 RSS-247 SETUP PHOTOS EXHIBIT - FINAL | Test Setup Photos | 2022-04-27 | PDF 2.8 MB |
| Test setup photos | Test Setup Photos | 2016-11-27 | PDF 841.2 KB |
| R13708588-E2 v3 15.247 RSS-247 BLE REPORT - FINAL | Test Report | 2021-10-29 | PDF 2.6 MB |
| R13708588-E3 v2 15.247 RSS-247 2.4 GHz WLAN Spotcheck REPORT only | Test Report | 2021-10-29 | PDF 1.2 MB |
| Test report | Test Report | 2016-07-06 | PDF 3.3 MB |
| Cover Letters_20211001_v1 - TH6220WF2006-FCC Agent Auth letter | Cover Letter(s) | 2021-10-29 | PDF 152 KB |
| FCC C2PC | Cover Letter(s) | 2021-10-29 | PDF 149.9 KB |
| TH6220WF2006 - FCC Confidentiality | Cover Letter(s) | 2021-10-29 | PDF 205.7 KB |
| Cover letter | Cover Letter(s) | 2016-07-06 | PDF 105.5 KB |
| Request for confidentiality | Cover Letter(s) | 2016-07-06 | PDF 124 KB |
| R13708588-E4 v3 MPE REPORT-FINAL | RF Exposure Info | 2021-10-29 | PDF 279.5 KB |
| RF Exposure | RF Exposure Info | 2016-07-06 | PDF 786.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 132.5 KB | |
| Frequency Block Diagram Metadata only | Block Diagram | PDF 134.8 KB | |
| Schematics Metadata only | Schematics | PDF 72 KB | |
| Schematics_20211001_v1 - Radio_schematic-TH6220WF2006 Metadata only | Schematics | PDF 3 MB | |
| Operational Description Metadata only | Operational Description | PDF 36.4 KB | |
| TH6220WF01B_Theory of Operation Metadata only | Operational Description | PDF 240.4 KB | |
| antenna_info Metadata only | Operational Description | PDF 112.6 KB | |
| Parts List & Tune Up Info._20211001_v1 - antenna_info-TH6220WF2006 Metadata only | Parts List/Tune Up Info | PDF 112.6 KB |
Application Information
| Application ID | Wcj+jHnTImANbvACd2OdKQ== |
|---|---|
| Final Action Date | 2021-10-29 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0004788345 |
| Model | TH6220WF01 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Thermostat |
| Responsible Party | Christian Fouth, Global Leader Wireless Testing, christian.fouth@resideo.com  , 540-656-6372 |
| Technical Contact | Haley Ackun, UL LLC, haley.ackun@ul.com  , 919-549-1315 |
| Test Firm | Steven Thompson, UL LLC, steven.d.thompson@ul.com , 919 549 1430 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 04/27/2022 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II Permissive changes to enable Blue Tooth operation with adding additional models. Output power is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Wcj+jHnTImANbvACd2OdKQ== | 2021-10-29 | Class II permissive change or modification of presently authorized equipment |
| d2c4res07S+/UoO1IV0Ydw== | 2016-07-06 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application Wcj+jHnTImANbvACd2OdKQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 10/29/2021 Application Dated: 10/29/2021 |
| Ademco Inc |
| 1985 Douglas Drive |
| Golden Valley, MN 55422-3922 |
| Attention: Christian Fouth , Global Leader Wireless Testing |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HS9-TH6220WF01 |
| Name of Grantee: | Ademco Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | Thermostat |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0063 | |||
| 15C | 2405.0 - 2480.0 | 0.0794 |
| Class II Permissive changes to enable Blue Tooth operation with adding additional models. Output power is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application Wcj+jHnTImANbvACd2OdKQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ademco Inc 1985 Douglas Drive Golden Valley, MN 55422-3922 United States |
Date of Grant: 10/29/2021 Application Dated: 10/29/2021 |
| Attention: Christian Fouth , Global Leader Wireless Testing |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | HS9-TH6220WF01 |
| Name of Grantee: | Ademco Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | Thermostat |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0063 | |||
| 15C | 2405.0 - 2480.0 | 0.0794 |
| Class II Permissive changes to enable Blue Tooth operation with adding additional models. Output power is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
