HN1510 Data Transceiver External Photos - FCC ID HSW-HN1510

FCC ID HSW-HN1510

External Photos

Data Transceiver

by Murata Electronics North America

Document preview loads when visible.

Document Details

FCC IDHSW-HN1510
Document ID250933
Document TypeExternal Photos
DescriptionExternal Photos
Document Title02-0114_HN1510
ApplicantMurata Electronics North America
Equipment ClassData Transceiver
Product CodeHN1510
Application IDcZkovOd36Z744vGIgMf9zA==
Application PurposeOriginal Equipment
Application Date2003-01-07
Frequency Range2401.69-2469.89 MHz
FRN0024753089
Test FirmUS Tech
Certified ByTimothy R. Johnson Engineering Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2002-06-18
Available2003-01-07
Created2002-06-17
Modified2002-06-17
Pages3
File TypeAdobe Acrobat PDF
File Size150854
File SHA-256ae99ae90f6ad47be69cad87bdaa181cb7e1aeac47fa08ec6e0f62cdf6e193e76
PDF Metadata AuthorTJohnson
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows) TJohnson
FCC.gov SourcesFCC.gov 250933
