CTL4100WLA Pen Tablet Teardown Internal... - FCC ID HV4CTL4100WLA
FCC ID HV4CTL4100WLA
Internal Photos
Pen Tablet
by Wacom Co Ltd
Document preview loads when visible.
Document Details
| FCC ID | HV4CTL4100WLA |
|---|---|
| Document ID | 5551067 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Wacom Co Ltd |
| Equipment Class | Pen Tablet |
| Product Code | CTL4100WLA |
| Application ID | 75EMHl88bFfDti6h9JZfmg== |
| Application Purpose | Original Equipment |
| Application Date | 2021-11-24 |
| Frequency Range | 0.667 MHz |
| FRN | 0005939525 |
| Test Firm | Sporton International Inc. Hsinhua Laboratory |
| Certified By | Leo Huang Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 02/22/2022 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2021-11-23 |
| Available | 2022-02-22 |
| Created | 2021-11-19 |
| Modified | 2021-11-19 |
| Pages | 11 |
| File Type | Adobe Acrobat PDF |
| File Size | 2022656 |
| File SHA-256 | fcd5daac348580d189752aea4e4d2f84cde87fc46aa62020c8aa59f6ec0e0b0e |
| PDF Metadata Author | Amber Chiu (邱淑卿) |
| PDF Metadata Producer | Amber Chiu (邱淑卿) Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 5551067, FCC.gov 5551051 |
