XD Serial/USB Digitizer with Pen and/or Mouse... - FCC ID HV4XD
FCC ID HV4XD
Tech Description
Serial/USB Digitizer with Pen and/or Mouse
by Wacom Co Ltd
Document preview loads when visible.
Document Details
| FCC ID | HV4XD |
|---|---|
| Document ID | 155071 |
| Document Type | Operational Description |
| Description | Tech Description |
| Document Title | Operational Description |
| Applicant | Wacom Co Ltd |
| Equipment Class | Serial/USB Digitizer with Pen and/or Mouse |
| Product Code | XD |
| Application ID | g0QO5UW0pnsrGOgNYocRdA== |
| Application Purpose | Original Equipment |
| Application Date | 2001-06-15 |
| Frequency Range | 0.571 MHz |
| FRN | 0005939525 |
| Test Firm | Tokin EMC Engineering Co., Ltd. |
| Certified By | Michihisa Yamazaki Executive Vice President |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2001-06-15 |
| Available | 2001-06-15 |
| Created | 2001-06-08 |
| Modified | 2001-06-08 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 4828 |
| File SHA-256 | e0c8e6fd0613bf1138e0e5a517a2b0735611fd3c2fc015cf9b7621d40449f5ce |
| PDF Metadata Author | WACOM |
| PDF Metadata Producer | Acrobat Distiller 4.05 for Windows Microsoft Word 9.0 |
| FCC.gov Sources | FCC.gov 155071 |
