5054LR 802.11a Wireless Tsunami 5054-R... - FCC ID HZB-5054-LR

FCC ID HZB-5054-LR

Test Setup Photos

802.11a Wireless Tsunami 5054-R Radio

by Proxim Wireless Corporation

Document preview loads when visible.

Document Details

FCC IDHZB-5054-LR
Document ID749934
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title2
ApplicantProxim Wireless Corporation
Equipment Class802.11a Wireless Tsunami 5054-R Radio
Product Code5054LR
Application IDxjRKgahk4uJm4M3OSAfE9w==
Application PurposeClass II Permissive Change
Application Date2007-02-09
Frequency Range5260-5320 MHz
FRN0014765044
Test FirmBay Area Compliance Laboratory
Certified ByCaroline Yu Regulatory Compliance Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2007-01-23
Available2007-02-09
Created2007-01-22
Modified2007-01-22
Pages1
File TypeAdobe Acrobat PDF
File Size105955
File SHA-25644ab80a85b10656e712fef16db66b35fe41dffb758e781fc63c93dca29c68f65
PDF Metadata Authortina
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 749934
