B620 Mini-PCI 11M Wireless Lan Card External Photos - FCC ID I88B620
FCC ID I88B620
External Photos
Mini-PCI 11M Wireless Lan Card
Document preview loads when visible.
Document Details
| FCC ID | I88B620 |
|---|---|
| Document ID | 335070 |
| Document Type | External Photos |
| Description | External Photos |
| Document Title | Photo 1: Outlook |
| Applicant | ZyXEL Communications Corporation |
| Equipment Class | Mini-PCI 11M Wireless Lan Card |
| Product Code | B620 |
| Application ID | 6czmDYP3XnMJP5eKT+grYQ== |
| Application Purpose | Original Equipment |
| Application Date | 2003-06-25 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0021059092 |
| Test Firm | Intertek Testing Services Taiwan Ltd. |
| Certified By | Elton Chen |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-06-25 |
| Available | 2003-06-25 |
| Created | 2003-06-03 |
| Modified | 2003-06-03 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 234394 |
| File SHA-256 | f3bfcc5e28cdfe808d2fcaefc983bcb0eb33fd87fa7a7d830a61a3a615e74b71 |
| PDF Metadata Author | Doug Noble |
| PDF Metadata Producer | Acrobat Distiller 5.0 (Windows) Doug Noble |
| FCC.gov Sources | FCC.gov 335070 |
