VP43XX04 Remote Control Test Setup Photos - FCC ID IE3VP43XX04

FCC ID IE3VP43XX04

Test Setup Photos

Remote Control

by SMK-Link Electronics

Document preview loads when visible.

Document Details

FCC IDIE3VP43XX04
Document ID490898
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Titlex-axis.PDF
ApplicantSMK-Link Electronics
Equipment ClassRemote Control
Product CodeVP43XX04
Application IDvxg29ya1Wq/GV84CaFY86A==
Application PurposeOriginal Equipment
Application Date2004-11-23
Frequency Range2403-2480 MHz
FRN0018034116
Test FirmCompatible Electronics
Certified ByRuby Hall Lab Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-11-23
Available2004-11-23
Created2004-07-30
Modified2004-08-07
Pages3
File TypeAdobe Acrobat PDF
File Size364249
File SHA-2564136c375c98b47bbf242b91bc6fa59b5a84976e2bbd5d1b6adeaa94bbb1ce51b
PDF Metadata AuthorReport1
PDF Metadata CreatorMicrosoft Photo Editor
PDF Metadata ProducerAcrobat PDFWriter 4.0 for Windows
FCC.gov SourcesFCC.gov 490898
