FCC ID IFHOPTIMAD
2.4GHz Aircraft Receiver
by Hitec RCD Inc.
Grantee Code: IFH Product Code: OPTIMAD
Latest application date: 2016-08-23
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2409.2-2474 MHz | Original Equipment | 2016-08-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-08-23 | PDF 722.9 KB |
| Internal Photos | Internal Photos | 2016-08-23 | PDF 539.9 KB |
| External Photos | External Photos | 2016-08-23 | PDF 437.3 KB |
| Label | ID Label/Location Info | 2016-08-23 | PDF 133.9 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-23 | PDF 306 KB |
| Test Report | Test Report | 2016-08-23 | PDF 3 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-08-23 | PDF 35.7 KB |
| Product Certification Representative Auth Letter | Cover Letter(s) | 2016-08-23 | PDF 39.2 KB |
| RF Exposure | RF Exposure Info | 2016-08-23 | PDF 303.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 93.5 KB | |
| Schematics Metadata only | Schematics | PDF 92.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 142.3 KB |
Application Information
| Application ID | 0kgO0byhSOITXC9fXHOjMQ== |
|---|---|
| Final Action Date | 2016-08-23 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0004317129 |
| Model | OPTIMAD |
| Frequency Range | 2409.2-2474 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | 2.4GHz Aircraft Receiver |
| Responsible Party | Tony Ohm, Service Dept. Manager, tonyo@hitecrcd.com  , 858-748-8440 |
| Test Firm | Sung-Su Lim, KCTL INC, sungsu.lim@kctl.co.kr  , +82-31-326-6713 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 0kgO0byhSOITXC9fXHOjMQ== | 2016-08-23 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2409.2-2474 MHz | 0.0314000 | 15C |
Grants
TCB Grant - Application 0kgO0byhSOITXC9fXHOjMQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 08/23/2016 Application Dated: 08/23/2016 |
| Hitec RCD Inc. |
| 12115 Paine Street |
| Poway, CA 92064 |
| Attention: Tony Ohm , Service Dept. Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | IFHOPTIMAD |
| Name of Grantee: | Hitec RCD Inc. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 2.4GHz Aircraft Receiver |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2409.2 - 2474.0 | 0.0314 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application 0kgO0byhSOITXC9fXHOjMQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Hitec RCD Inc. 12115 Paine Street Poway, CA 92064 United States |
Date of Grant: 08/23/2016 Application Dated: 08/23/2016 |
| Attention: Tony Ohm , Service Dept. Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | IFHOPTIMAD |
| Name of Grantee: | Hitec RCD Inc. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 2.4GHz Aircraft Receiver |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2409.2 - 2474.0 | 0.0314 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
