T56GS1 Portable Tri-Mode Dual-Band... - FCC ID IHDT56GS1
FCC ID IHDT56GS1
Exhibit 7 HAC Photos
Portable Tri-Mode Dual-Band Transceiver with BT
Document preview loads when visible.
Document Details
| FCC ID | IHDT56GS1 |
|---|---|
| Document ID | 715274 |
| Document Type | Test Setup Photos |
| Description | Exhibit 7 HAC Photos |
| Document Title | HAC Test Report for RF Emissions IHDT56GS1 |
| Applicant | Motorola Mobility LLC |
| Equipment Class | Portable Tri-Mode Dual-Band Transceiver with BT |
| Product Code | T56GS1 |
| Application ID | M/blIi66Xb/0qEDyn7H/xQ== |
| Application Purpose | Original Equipment |
| Application Date | 2006-10-13 |
| Frequency Range | 1851.25-1908.75 MHz |
| FRN | 0004321311 |
| Test Firm | Motorola Inc. |
| Certified By | Randy Ortanez President |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 11/27/2006 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | Yes |
| Submitted | 2006-10-13 |
| Available | 2006-11-27 |
| Created | 2006-09-05 |
| Modified | 2006-09-28 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 398887 |
| File SHA-256 | ddf28a76fc4a692f7346e2dca52ccf1f9fa9e871621f77b3ca05f90b0526a741 |
| PDF Metadata Author | w30119 |
| PDF Metadata Producer | Acrobat Distiller 6.0 (Windows) w30119 |
| FCC.gov Sources | FCC.gov 715274 |
