T56VF3 Mobile Cellular Phone Label Diagram - FCC ID IHDT56VF3

FCC ID IHDT56VF3

Label

Mobile Cellular Phone

by Motorola Mobility LLC

Barcode information

Validated product identifiers extracted from the generated document image; label documents may also include identifiers from available document text.

Code 128 ]C0

Barcode typeCode 128 ]C0
Decoded value1234567890

Document preview loads when visible.

Document Details

FCC IDIHDT56VF3
Document ID3220583
Document TypeID Label/Location Info
DescriptionLabel
ApplicantMotorola Mobility LLC
Equipment ClassMobile Cellular Phone
Product CodeT56VF3
Application IDhIjvORyg2Jgvi4n1XWIo0Q==
Application PurposeOriginal Equipment
Application Date2016-12-08
Frequency Range1850.2-1909.8 MHz
FRN0004321311
Test FirmSPORTON International Inc.
Certified ByJones Tsai Director
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/06/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-12-07
Available2016-12-08
Created2017-12-19
Modified2017-12-19
Pages1
File TypeAdobe Acrobat PDF
File Size48532
File SHA-256f79fd30e225f0ddffbd7e5fc5666fc1072ec9c83299e2a209931674cff2b24db
PDF Metadata ProducerGPL Ghostscript 9.18
FCC.gov SourcesFCC.gov 3220583, FCC.gov 3220869, FCC.gov 3220836, FCC.gov 3220772, FCC.gov 3220664
