T6AA1 motorola smart stylus Teardown Internal... - FCC ID IHDT6AA1
FCC ID IHDT6AA1
Internal Photos_Part 2
motorola smart stylus
Document preview loads when visible.
Document Details
| FCC ID | IHDT6AA1 |
|---|---|
| Document ID | 5686033 |
| Document Type | Internal Photos |
| Description | Internal Photos_Part 2 |
| Applicant | Motorola Mobility LLC |
| Equipment Class | motorola smart stylus |
| Product Code | T6AA1 |
| Application ID | QWGR30jSnHvGOwgO1urS6Q== |
| Application Purpose | Original Equipment |
| Application Date | 2022-02-17 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0004321311 |
| Test Firm | Centre Testing International Group Co., Ltd |
| Certified By | Mina Xu |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 08/17/2022 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-02-17 |
| Available | 2022-08-17 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 514393 |
| File SHA-256 | 852ee2c6b790888e61ae8bffe9b46d9f579c062a20f8548794ddd8a7d1b239a5 |
| FCC.gov Sources | FCC.gov 5686033 |
Related FCC Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2022-08-17 | PDF 966.7 KB |
| Internal Photos | Internal Photos | 2022-08-17 | PDF 3.7 MB |
| Internal Photos_Part 2 | Internal Photos | 2022-08-17 | PDF 502.3 KB |
| External Photos | External Photos | 2022-08-17 | PDF 4 MB |
| Label | ID Label/Location Info | 2022-02-17 | PDF 1.5 MB |
| Setup Photos | Test Setup Photos | 2022-08-17 | PDF 268.8 KB |
| Test Report_15C | Test Report | 2022-02-17 | PDF 641.9 KB |
| Test Report_BLE | Test Report | 2022-02-17 | PDF 1.6 MB |
| Test Report_BLE Appendix | Test Report | 2022-02-17 | PDF 2.7 MB |
| FCC SDoc Attestation Letter | Cover Letter(s) | 2022-02-17 | PDF 153.9 KB |
| CONF-Letter | Cover Letter(s) | 2022-02-17 | PDF 142.2 KB |
| Conf Letter | Cover Letter(s) | 2022-02-17 | PDF 142.2 KB |
| FCC SDoc Letter | Cover Letter(s) | 2022-02-17 | PDF 153.9 KB |
| POA | Cover Letter(s) | 2022-02-17 | PDF 163 KB |
| MPE | RF Exposure Info | 2022-02-17 | PDF 333.3 KB |
| Block Metadata only | Block Diagram | PDF 626 KB | |
| SCH Metadata only | Schematics | PDF 206.5 KB | |
| Operation Description Metadata only | Operational Description | PDF 73.8 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 125.8 KB |
