TX28 Remote Control Block Diagram - FCC ID IN2TX28
FCC ID IN2TX28
Block diagram
Remote Control
Document preview loads when visible.
Document Details
| FCC ID | IN2TX28 |
|---|---|
| Document ID | 1195777 |
| Document Type | Block Diagram |
| Description | Block diagram |
| Document Title | fcc block diagram.xls |
| Applicant | Hunter Fan Company |
| Equipment Class | Remote Control |
| Product Code | TX28 |
| Application ID | wDZPF8+7Odz/eKuv32QejA== |
| Application Purpose | Original Equipment |
| Application Date | 2009-11-06 |
| Frequency Range | 350 MHz |
| FRN | 0006777569 |
| Test Firm | Intertek Testing Services NA Inc. |
| Certified By | Richard Bianco EMC Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2009-11-06 |
| Available | 2009-11-06 |
| Created | 2009-10-22 |
| Modified | 2009-10-22 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 20385 |
| File SHA-256 | 6f72aea3cf347b092a151409652e59910db2407ebb79ef310087ce8feadce599 |
| PDF Metadata Author | Terre.Wolak |
| PDF Metadata Creator | PScript5.dll Version 5.2 |
| PDF Metadata Producer | Acrobat Distiller 6.0 (Windows) |
| FCC.gov Sources | FCC.gov 1195777 |
