RMO221UP WIRELESS OPTICAL MOUSE Schematics - FCC ID IOWRMO221UP

FCC ID IOWRMO221UP

SCHEMATICS

WIRELESS OPTICAL MOUSE

by Chic Technology Corporation

Document preview loads when visible.

Document Details

FCC IDIOWRMO221UP
Document ID394531
Document TypeSchematics
DescriptionSCHEMATICS
Document TitleSCHEMATIC1 : PAGE1
ApplicantChic Technology Corporation
Equipment ClassWIRELESS OPTICAL MOUSE
Product CodeRMO221UP
Application IDUhOAFMMYvSRD40wjk2qNXg==
Application PurposeOriginal Equipment
Application Date2004-01-06
Frequency Range26.96-27.28 MHz
FRN0005408562
Test FirmTraining Research Co., Ltd
Certified ByMATTHEW KU MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-02-05
Available2004-01-06
Created2003-11-28
Modified2003-12-02
Pages3
File TypeAdobe Acrobat PDF
File Size54433
File SHA-256b0203ae8f1cdb7a82dcea5f3f82f2b3fcaf203bb43eb5379b1841d51541e34b6
PDF Metadata AuthorJacky_Wang
PDF Metadata ProducerAcrobat PDFWriter 4.0Windows NT ª© Jacky_Wang
FCC.gov SourcesFCC.gov 394531
