FCC ID IPH-03009
Bluetooth LE and ANT+ Transmitter
by Garmin International Inc
Grantee Code: IPH Product Code: 03009
Latest application date: 2016-03-21
Device Images
FCC ID Device Details
| FCC ID | IPH-03009 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | IPH |
| Product Code | 03009 |
| Applicant Business | Garmin International Inc 🇺🇸 |
| Related Domains |  garmin.com |
| Equipment Class | Bluetooth LE and ANT+ Transmitter |
| Test Firm | Compliance Worldwide, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-03-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-03-21 | PDF 4.8 MB |
| Internal Photos | Internal Photos | 2016-03-21 | PDF 554.1 KB |
| External Photo | External Photos | 2016-03-21 | PDF 504.5 KB |
| Label Location | ID Label/Location Info | 2016-03-21 | PDF 12 KB |
| Label Sample | ID Label/Location Info | 2016-03-21 | PDF 12.6 KB |
| Test Setup Photos | Test Setup Photos | 2016-03-21 | PDF 574.3 KB |
| Test Report | Test Report | 2016-03-21 | PDF 4.3 MB |
| Agent Authorization Letter | Cover Letter(s) | 2016-03-21 | PDF 549.4 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-03-21 | PDF 1.3 MB |
| Grantee Contact POA | Cover Letter(s) | 2016-03-21 | PDF 189.4 KB |
| RF Exposure Info | RF Exposure Info | 2016-03-21 | PDF 109.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 504.1 KB | |
| Schematics Metadata only | Schematics | PDF 105.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 501.4 KB |
Application Information
| Application ID | kKBsJycN4NmMKo4Xh+yEnw== |
|---|---|
| Final Action Date | 2016-03-21 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005088588 |
| Model | 03009 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Bluetooth LE and ANT+ Transmitter |
| Responsible Party | Douglas Kealey, Manager Environmental and Regulatory Affairs, doug.kealey@garmin.com , 9134405210 |
| Test Firm | Mark McSweeney, Compliance Worldwide, Inc., mark@complianceworldwide.com  , 603-887-3903 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| kKBsJycN4NmMKo4Xh+yEnw== | 2016-03-21 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0020000 | 15C |
Grants
TCB Grant - Application kKBsJycN4NmMKo4Xh+yEnw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/21/2016 Application Dated: 03/21/2016 |
| Garmin International Inc |
| 1200 E. 151st. Street |
| Olathe, KS 66062 |
| Attention: Douglas Kealey , Manager Environmental and Regulatory Affairs |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | IPH-03009 |
| Name of Grantee: | Garmin International Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | Bluetooth LE and ANT+ Transmitter |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.002 |
| Power listed is conducted. |
EAS Grant - Application kKBsJycN4NmMKo4Xh+yEnw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Garmin International Inc 1200 E. 151st. Street Olathe, KS 66062 United States |
Date of Grant: 03/21/2016 Application Dated: 03/21/2016 |
| Attention: Douglas Kealey , Manager Environmental and Regulatory Affairs |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | IPH-03009 |
| Name of Grantee: | Garmin International Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | Bluetooth LE and ANT+ Transmitter |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.002 |
| Power listed is conducted. |
