04272 Low Power Digital Device Transmitter... - FCC ID IPH-04272
FCC ID IPH-04272
External Photos
Low Power Digital Device Transmitter
Document preview loads when visible.
Document Details
| FCC ID | IPH-04272 |
|---|---|
| Document ID | 5484250 |
| Document Type | External Photos |
| Description | External Photos |
| Applicant | Garmin International Inc |
| Equipment Class | Low Power Digital Device Transmitter |
| Product Code | 04272 |
| Application ID | Lp58RSSsk9xKAXc2HCs2gg== |
| Application Purpose | Original Equipment |
| Application Date | 2021-10-25 |
| Frequency Range | 13.56 MHz |
| FRN | 0005088588 |
| Test Firm | Rogers Labs, Inc. |
| Certified By | Scot D. Rogers President |
| Short-Term Confidentiality | Yes |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 04/23/2022 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2021-10-08 |
| Available | 2022-04-23 |
| Created | 2021-10-04 |
| Modified | 2021-10-04 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 1011735 |
| File SHA-256 | c09d8f0d24716484fc3a4d35552ae23f8eaabe9d9f2eaa348babe4587b56f03f |
| PDF Metadata Producer | Microsoft® Word for Microsoft 365 Microsoft® Word for Microsoft 365 |
| FCC.gov Sources | FCC.gov 5484250 |
