0282320 Dog Collar Teardown Internal Photos - FCC ID IPH-0282320
FCC ID IPH-0282320
Internal Photos
Dog Collar
Document preview loads when visible.
Document Details
| FCC ID | IPH-0282320 |
|---|---|
| Document ID | 5871979 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Garmin International Inc |
| Equipment Class | Dog Collar |
| Product Code | 0282320 |
| Application ID | bIEK4WveVjgMwqcpBzuU7w== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2022-05-13 |
| Frequency Range | 151.82-154.6 MHz |
| FRN | 0005088588 |
| Test Firm | Nebraska Center for Excellence in Electronics |
| Certified By | Nic Johnson Technical Manager |
| Short-Term Confidentiality | Yes |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 11/09/2022 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-05-11 |
| Available | 2022-11-09 |
| Created | 2021-08-09 |
| Modified | 2021-08-09 |
| Pages | 10 |
| File Type | Adobe Acrobat PDF |
| File Size | 4854695 |
| File SHA-256 | 1da94e9468f88e9adde8e4d3a3e1ccc2dfcf72ab680f582d403851916fd906b5 |
| PDF Metadata Author | Irish, Dan |
| PDF Metadata Producer | Irish, Dan Adobe PDF Library 21.5.92 |
| FCC.gov Sources | FCC.gov 5871979 |
