04676 Marine Radar Label Diagram - FCC ID IPH-04676

FCC ID IPH-04676

Label and Placement

Marine Radar

by Garmin International Inc

Document preview loads when visible.

Document Details

FCC IDIPH-04676
Document ID6529129
Document TypeID Label/Location Info
DescriptionLabel and Placement
ApplicantGarmin International Inc
Equipment ClassMarine Radar
Product Code04676
Application IDQnXhKqKjtQDyhDajrotw4w==
Application PurposeOriginal Equipment
Application Date2023-09-05
Frequency Range9300-9500 MHz
FRN0005088588
Test FirmRogers Labs, Inc.
Certified ByMichael Moranha Lead Compliance Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/03/2024
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2023-05-15
Available2023-09-05
Created2023-04-03
Modified2023-04-03
Pages1
File TypeAdobe Acrobat PDF
File Size32636
File SHA-2566b0503c2d9a0385586c3532f0091475f169e6feee2f00a4646bf7ba71db0c2ea
FCC.gov SourcesFCC.gov 6529129
