FCC ID IPH-A2557
Digital Transmission System 2412-2462 MHz
by Garmin International Inc
Grantee Code: IPH Product Code: A2557
Latest application date: 2016-02-01
Device Images
FCC ID Device Details
| FCC ID | IPH-A2557 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | IPH |
| Product Code | A2557 |
| Applicant Business | Garmin International Inc 🇺🇸 |
| Related Domains |  garmin.com |
| Equipment Class | Digital Transmission System 2412-2462 MHz |
| Test Firm | Rogers Labs, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-02-01 |
| 2402-2480 MHz | Original Equipment | 2016-02-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-02-01 | PDF 2.9 MB |
| Users Manual 1 | Users Manual | 2016-02-01 | PDF 1.1 MB |
| Users Manual 2 | Users Manual | 2016-02-01 | PDF 489.9 KB |
| Internal Photos | Internal Photos | 2016-02-01 | PDF 563.5 KB |
| External Photos | External Photos | 2016-02-01 | PDF 1,000 KB |
| Label Sample | ID Label/Location Info | 2016-02-01 | PDF 106.7 KB |
| Test Setup Photos | Test Setup Photos | 2016-02-01 | PDF 1.3 MB |
| Test Report DTS | Test Report | 2016-02-01 | PDF 1.9 MB |
| Test Report DXX | Test Report | 2016-02-01 | PDF 1.9 MB |
| Agent Authorization Letter | Cover Letter(s) | 2016-02-01 | PDF 188.9 KB |
| Agent Letter | Cover Letter(s) | 2016-02-01 | PDF 188.9 KB |
| Authorization Letter | Cover Letter(s) | 2016-02-01 | PDF 159.1 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-02-01 | PDF 280.1 KB |
| SAR Exclusion Calculation | RF Exposure Info | 2016-02-01 | PDF 206.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 448.5 KB | |
| Schematics Metadata only | Schematics | PDF 754.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 281.1 KB |
Application Information
| Application ID | YanGOTlvddIPijiTknerVw== |
|---|---|
| Final Action Date | 2016-02-01 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005088588 |
| Model | A2557 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Digital Transmission System 2412-2462 MHz |
| Responsible Party | Douglas Kealey, Manager Environmental and Regulatory Affairs, doug.kealey@garmin.com , 9134405210 |
| Test Firm | Scot Rogers, Rogers Labs, Inc., rogers@pixius.net  , 913-837-3214 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| YanGOTlvddIPijiTknerVw== | 2016-02-01 | Original Equipment |
| QDLRaZI/wBh/SiOqm3ui8w== | 2016-02-01 | Original Equipment |
Grants
TCB Grant - Application YanGOTlvddIPijiTknerVw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 02/01/2016 Application Dated: 02/01/2016 |
| Garmin International Inc |
| 1200 E. 151st. Street |
| Olathe, KS 66062 |
| Attention: Douglas Kealey , Manager Environmental and Regulatory Affairs |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | IPH-A2557 |
| Name of Grantee: | Garmin International Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | Digital Transmission System 2412-2462 MHz |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.01 |
| Power listed is conducted |
