85024 Digital Modulated Radio Label Diagram - FCC ID JF6-8502-4

FCC ID JF6-8502-4

FCC Label

Digital Modulated Radio

by Alcatel USA Marketing, Inc.

Document preview loads when visible.

Document Details

FCC IDJF6-8502-4
Document ID588213
Document TypeID Label/Location Info
DescriptionFCC Label
Document TitlePro/ENGINEER - 3EM16212AGAA
ApplicantAlcatel USA Marketing, Inc.
Equipment ClassDigital Modulated Radio
Product Code85024
Application IDaTltfYKsmECwexM12EShxg==
Application PurposeOriginal Equipment
Application Date2005-11-18
Frequency Range2305-2360 MHz
FRN0021916358
Test FirmAlcatel North America
Certified ByJake Holland, III Project Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-10-04
Available2005-11-18
Created2005-10-03
Modified2005-10-03
Pages3
File TypeAdobe Acrobat PDF
File Size136282
File SHA-256a2fbfbfc6c299088c3de32eec5ff90cb11830ecff6338e690c2d96447d1eb864
PDF Metadata Authorpstewart
PDF Metadata ProducerGPL Ghostscript 8.15 PScript5.dll Version 5.2.2
FCC.gov SourcesFCC.gov 588213
