R2100D Wireless Microphone Receiver Teardown... - FCC ID JFZR2100D

FCC ID JFZR2100D

INTERNAL PHOTOS 4

Wireless Microphone Receiver

by Audio-Technica Corporation

INTERNAL PHOTOS 4

Document Details

FCC IDJFZR2100D
Document ID489202
Document TypeInternal Photos
DescriptionINTERNAL PHOTOS 4
ApplicantAudio-Technica Corporation
Equipment ClassWireless Microphone Receiver
Product CodeR2100D
Application ID1BL9HH/+oH1J+yZV/LIosg==
Application PurposeOriginal Equipment
Application Date2004-11-16
Frequency Range655-680 MHz
FRN0028730448
Test FirmTimco Engineering, Inc.
Certified ByHisao Sugiyama
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-11-17
Available2004-11-16
Pages0
File TypeJPEG Image
File Size311957
File SHA-256596347ab63a50b22f3f5132bda9899a82733b1c4acd4e18275d03beea337d7f2
FCC.gov SourcesFCC.gov 489202
