AR9381DB24 Wireless Data Gateway Test... - FCC ID JI5-AR9381DB24

FCC ID JI5-AR9381DB24

Test Setup Photos

Wireless Data Gateway

by SMC Networks Inc

Document preview loads when visible.

Document Details

FCC IDJI5-AR9381DB24
Document ID2580638
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleAPPENDIX A. TEST PHOTOS_FR4N2724
ApplicantSMC Networks Inc
Equipment ClassWireless Data Gateway
Product CodeAR9381DB24
Application IDJq03ZXwQE1grnWI2fwGEtg==
Application PurposeOriginal Equipment
Application Date2015-04-10
Frequency Range2412-2462 MHz
FRN0021573001
Test FirmSporton International Inc.
Certified ByLeo Huang Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/07/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2015-04-10
Available2015-10-07
Created2015-02-16
Modified2015-03-17
Pages5
File TypeAdobe Acrobat PDF
File Size321372
File SHA-25676f09cb939bdb759f6144a8fcad1278f3398dddbcc00e1e1d05482e10f10d718
PDF Metadata AuthorWendyPan
PDF Metadata ProducerWendyPan Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 2580638
