221729 Wireless Keyboard Block Diagram - FCC ID JNZ221729

FCC ID JNZ221729

Block Diagram

Wireless Keyboard

by Logitech Far East Ltd

Document preview loads when visible.

Document Details

FCC IDJNZ221729
Document ID358234
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantLogitech Far East Ltd
Equipment ClassWireless Keyboard
Product Code221729
Application IDkcxDMcD6K5BWZC2aYBBWFw==
Application PurposeOriginal Equipment
Application Date2003-09-18
Frequency Range27.145 MHz
FRN0007134034
Test FirmDEKRA Testing and Certification Co., Ltd.
Certified ByGene Chang President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-09-18
Available2003-09-18
Created2003-09-17
Modified2003-09-17
Pages1
File TypeAdobe Acrobat PDF
File Size48203
File SHA-256dccbb2ca34d7a922b1d43ac8192f4d0d34858980174e768291bf5e41431cdee1
PDF Metadata ProducerAcrobat 5.0 Image Conversion Plug-in for Windows Acrobat 5.0 Image Conversion Plug-in for Windows
FCC.gov SourcesFCC.gov 358234
