FCC ID JOYKA36
Module
by Kyocera Corporation
Grantee Code: JOY Product Code: KA36
Latest application date: 2016-06-30
Device Images
FCC ID Device Details
| FCC ID | JOYKA36 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | JOY |
| Product Code | KA36 |
| Applicant Business | Kyocera Corporation 🇯🇵 |
| Related Domains |  kyocera.jp |
| Equipment Class | Module |
| Test Firm | TUV SUD Zacta Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 706.5-713.5 MHz | Class II permissive change or modification of presently authorized equipment | 2016-06-30 |
| 701.5-713.5 MHz | Original Equipment | 2015-09-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-06-30 | PDF 678.5 KB |
| User manual | Users Manual | 2016-02-28 | PDF 333.1 KB |
| Internal photos | Internal Photos | 2016-02-28 | PDF 275.7 KB |
| External photos | External Photos | 2016-06-30 | PDF 487.9 KB |
| External photos | External Photos | 2016-02-28 | PDF 308.4 KB |
| Label format and location | ID Label/Location Info | 2016-06-30 | PDF 113.7 KB |
| Label format and location | ID Label/Location Info | 2015-09-01 | PDF 62 KB |
| Test setup photos | Test Setup Photos | 2016-06-30 | PDF 317.9 KB |
| Test setup photos | Test Setup Photos | 2016-02-28 | PDF 448.7 KB |
| Test report | Test Report | 2016-06-30 | PDF 934.4 KB |
| Part 22 H Test report 2 of 2 | Test Report | 2015-09-01 | PDF 1.7 MB |
| Part 22H Test report 1 of 2 | Test Report | 2015-09-01 | PDF 1.2 MB |
| Part 24E Test report 1 of 2 | Test Report | 2015-09-01 | PDF 1.3 MB |
| Part 24E Test report 2 of 2 | Test Report | 2015-09-01 | PDF 2.4 MB |
| Part 27 LTE band 12 test report | Test Report | 2015-09-01 | PDF 2.1 MB |
| Part 27 band 4 test report 1 of 2 | Test Report | 2015-09-01 | PDF 1.2 MB |
| Part 27 band 4 test report 2 of 2 | Test Report | 2015-09-01 | PDF 2.2 MB |
| Attestation letter | Attestation Statements | 2015-09-01 | PDF 48.4 KB |
| Agent authorization | Cover Letter(s) | 2016-06-30 | PDF 330.9 KB |
| C2PC letter | Cover Letter(s) | 2016-06-30 | PDF 126 KB |
| Request for confidentiality | Cover Letter(s) | 2016-06-30 | PDF 126.1 KB |
| Agent authorization | Cover Letter(s) | 2015-09-01 | PDF 82.9 KB |
| Request for modular approval | Cover Letter(s) | 2015-09-01 | PDF 177.2 KB |
| Request for permanent confidentiality | Cover Letter(s) | 2015-09-01 | PDF 70.8 KB |
| Request for short term confidentiality | Cover Letter(s) | 2015-09-01 | PDF 70.8 KB |
| RF exposure Info | RF Exposure Info | 2016-06-30 | PDF 150.8 KB |
| RF exposure Info | RF Exposure Info | 2015-09-01 | PDF 98.4 KB |
| Block diagram Metadata only | Block Diagram | PDF 86.7 KB | |
| Block diagram Metadata only | Block Diagram | PDF 99.7 KB | |
| Schematics Metadata only | Schematics | PDF 512 KB | |
| Schematics Metadata only | Schematics | PDF 568.7 KB | |
| Antenna specification Metadata only | Operational Description | PDF 1.4 MB | |
| Operational description Metadata only | Operational Description | PDF 37.3 KB | |
| Operational description Metadata only | Operational Description | PDF 37.2 KB | |
| Parts list Metadata only | Parts List/Tune Up Info | PDF 596.9 KB | |
| Tune up procedure Metadata only | Parts List/Tune Up Info | PDF 33.5 KB | |
| Tune-up procedur Metadata only | Parts List/Tune Up Info | PDF 39.4 KB |
Application Information
| Application ID | HrfeVvzO49aJTjTHexcZrg== |
|---|---|
| Final Action Date | 2016-06-30 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0021250543 |
| Model | KA36 |
| Frequency Range | 706.5-713.5 MHz |
| Equipment Class | PCB - PCS Licensed Transmitter |
| Device Description | Module |
| Responsible Party | Yoshikazu Yamamoto, Manager, Quality Assurance Department, yoshikazu.yamamoto.ke@kyocera.jp , +81-45-943-6253 |
| Test Firm | Jun Shimanuki, TUV SUD Zacta Ltd., jun.shimanuki@tuv-sud.jp  , 3013623033 |
| TCB Email | LST.FRE.CertNotice@ul.com  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II permissive change to disable LTE Band 12 and enable LTE Band 17 by software. Modular approval. Power output is conducted. Values listed for LTE operations are for the highest power and the widest bandwidth for each band and modulation. This device supports LTE bandwidths of: 1.4MHz, 3MHz, 5MHz, 10MHz in LTE Band 5; 1.4MHz,3MHz, 5MHz, 10MHz, 15MHz and 20MHz in LTE Band 2 and LTE Band 4; 5MHz and 10MHz in LTE Band 17. The maximum antenna gain is 4.9dBi in 1850-1910 MHz, 3.8dBi in 824-849 MHz, 4.0dBi in 1710-1755 MHz and 2.4dBi in 704-716 MHz. This transmitter is approved for use in mobile RF exposure use condition with the antenna(s) installed providing a separation distance of at least 20 cm from all persons. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| HrfeVvzO49aJTjTHexcZrg== | 2016-06-30 | Class II permissive change or modification of presently authorized equipment |
| +IbqPQsQ4Q9tPCX1+jNpXA== | 2015-09-01 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules |
|---|---|---|---|---|
| 701.5-713.5 MHz | 0.194 | 2.5ppm | 4M52G7W | 27 |
| 701.5-713.5 MHz | 0.152 | 2.5ppm | 4M53D7W | 27 |
| 704-711 MHz | 0.189 | 2.5ppm | 9M01G7W | 27 |
| 704-711 MHz | 0.15 | 2.5ppm | 9M01D7W | 27 |
| 706.5-713.5 MHz | 0.191 | 2.5ppm | 4M52G7W | 27 |
| 706.5-713.5 MHz | 0.147 | 2.5ppm | 4M53D7W | 27 |
| 709-711 MHz | 0.189 | 2.5ppm | 9M04G7W | 27 |
| 709-711 MHz | 0.153 | 2.5ppm | 9M03D7W | 27 |
| 826.5-846.5 MHz | 0.168 | 2.5ppm | 4M53G7W | 22H |
| 826.5-846.5 MHz | 0.135 | 2.5ppm | 4M53D7W | 22H |
| 829-844 MHz | 0.166 | 2.5ppm | 9M00G7W | 22H |
| 829-844 MHz | 0.132 | 2.5ppm | 8M99D7W | 22H |
| 1712.5-1752.5 MHz | 0.188 | 2.5ppm | 4M52G7W | 27 |
| 1712.5-1752.5 MHz | 0.15 | 2.5ppm | 4M52D7W | 27 |
| 1720-1745 MHz | 0.188 | 2.5ppm | 17M9G7W | 27 |
| 1720-1745 MHz | 0.148 | 2.5ppm | 17M9D7W | 27 |
| 1851.5-1908.5 MHz | 0.204 | 2.5ppm | 2M71G7W | 24E |
| 1851.5-1908.5 MHz | 0.162 | 2.5ppm | 2M72D7W | 24E |
| 1852.4-1907.6 MHz | 0.258 | 2.5ppm | 4M16F9W | 24E |
| 1860-1900 MHz | 0.2 | 2.5ppm | 18M0G7W | 24E |
| 1860-1900 MHz | 0.155 | 2.5ppm | 18M0D7W | 24E |
Grants
TCB Grant - Application HrfeVvzO49aJTjTHexcZrg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 06/30/2016 Application Dated: 06/30/2016 |
| Kyocera Corporation |
| 2-1-1 Kagahara, Tsuzuki-ku |
| Yokohama-shi, Kanagawa, 224-8502 Japan |
| Attention: Yoshikazu Yamamoto , Manager, Quality Assurance Department |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | JOYKA36 |
| Name of Grantee: | Kyocera Corporation |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.221 | 2.5 PM | 4M17F9W | |
| 22H | 829.0 - 844.0 | 0.166 | 2.5 PM | 9M00G7W | |
| 22H | 829.0 - 844.0 | 0.132 | 2.5 PM | 8M99D7W | |
| 22H | 826.5 - 846.5 | 0.168 | 2.5 PM | 4M53G7W | |
| 22H | 826.5 - 846.5 | 0.135 | 2.5 PM | 4M53D7W | |
| 27 | 709.0 - 711.0 | 0.189 | 2.5 PM | 9M04G7W | |
| 27 | 709.0 - 711.0 | 0.153 | 2.5 PM | 9M03D7W | |
| 27 | 706.5 - 713.5 | 0.191 | 2.5 PM | 4M52G7W | |
| 27 | 706.5 - 713.5 | 0.147 | 2.5 PM | 4M53D7W | |
| 24E | 1852.4 - 1907.6 | 0.258 | 2.5 PM | 4M16F9W | |
| 24E | 1860.0 - 1900.0 | 0.2 | 2.5 PM | 18M0G7W | |
| 24E | 1860.0 - 1900.0 | 0.155 | 2.5 PM | 18M0D7W | |
| 24E | 1851.5 - 1908.5 | 0.204 | 2.5 PM | 2M71G7W | |
| 24E | 1851.5 - 1908.5 | 0.162 | 2.5 PM | 2M72D7W | |
| 27 | 1720.0 - 1745.0 | 0.188 | 2.5 PM | 17M9G7W | |
| 27 | 1720.0 - 1745.0 | 0.148 | 2.5 PM | 17M9D7W | |
| 27 | 1712.5 - 1752.5 | 0.188 | 2.5 PM | 4M52G7W | |
| 27 | 1712.5 - 1752.5 | 0.15 | 2.5 PM | 4M52D7W |
| Class II permissive change to disable LTE Band 12 and enable LTE Band 17 by software. Modular approval. Power output is conducted. Values listed for LTE operations are for the highest power and the widest bandwidth for each band and modulation. This device supports LTE bandwidths of: 1.4MHz, 3MHz, 5MHz, 10MHz in LTE Band 5; 1.4MHz,3MHz, 5MHz, 10MHz, 15MHz and 20MHz in LTE Band 2 and LTE Band 4; 5MHz and 10MHz in LTE Band 17. The maximum antenna gain is 4.9dBi in 1850-1910 MHz, 3.8dBi in 824-849 MHz, 4.0dBi in 1710-1755 MHz and 2.4dBi in 704-716 MHz. This transmitter is approved for use in mobile RF exposure use condition with the antenna(s) installed providing a separation distance of at least 20 cm from all persons. |
EAS Grant - Application HrfeVvzO49aJTjTHexcZrg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Kyocera Corporation 2-1-1 Kagahara, Tsuzuki-ku Yokohama-shi, Kanagawa, 224-8502 Japan |
Date of Grant: 06/30/2016 Application Dated: 06/30/2016 |
| Attention: Yoshikazu Yamamoto , Manager, Quality Assurance Department |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | JOYKA36 |
| Name of Grantee: | Kyocera Corporation |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.221 | 2.5 PM | 4M17F9W | |
| 22H | 829.0 - 844.0 | 0.166 | 2.5 PM | 9M00G7W | |
| 22H | 829.0 - 844.0 | 0.132 | 2.5 PM | 8M99D7W | |
| 22H | 826.5 - 846.5 | 0.168 | 2.5 PM | 4M53G7W | |
| 22H | 826.5 - 846.5 | 0.135 | 2.5 PM | 4M53D7W | |
| 27 | 709.0 - 711.0 | 0.189 | 2.5 PM | 9M04G7W | |
| 27 | 709.0 - 711.0 | 0.153 | 2.5 PM | 9M03D7W | |
| 27 | 706.5 - 713.5 | 0.191 | 2.5 PM | 4M52G7W | |
| 27 | 706.5 - 713.5 | 0.147 | 2.5 PM | 4M53D7W | |
| 24E | 1852.4 - 1907.6 | 0.258 | 2.5 PM | 4M16F9W | |
| 24E | 1860.0 - 1900.0 | 0.2 | 2.5 PM | 18M0G7W | |
| 24E | 1860.0 - 1900.0 | 0.155 | 2.5 PM | 18M0D7W | |
| 24E | 1851.5 - 1908.5 | 0.204 | 2.5 PM | 2M71G7W | |
| 24E | 1851.5 - 1908.5 | 0.162 | 2.5 PM | 2M72D7W | |
| 27 | 1720.0 - 1745.0 | 0.188 | 2.5 PM | 17M9G7W | |
| 27 | 1720.0 - 1745.0 | 0.148 | 2.5 PM | 17M9D7W | |
| 27 | 1712.5 - 1752.5 | 0.188 | 2.5 PM | 4M52G7W | |
| 27 | 1712.5 - 1752.5 | 0.15 | 2.5 PM | 4M52D7W |
| Class II permissive change to disable LTE Band 12 and enable LTE Band 17 by software. Modular approval. Power output is conducted. Values listed for LTE operations are for the highest power and the widest bandwidth for each band and modulation. This device supports LTE bandwidths of: 1.4MHz, 3MHz, 5MHz, 10MHz in LTE Band 5; 1.4MHz,3MHz, 5MHz, 10MHz, 15MHz and 20MHz in LTE Band 2 and LTE Band 4; 5MHz and 10MHz in LTE Band 17. The maximum antenna gain is 4.9dBi in 1850-1910 MHz, 3.8dBi in 824-849 MHz, 4.0dBi in 1710-1755 MHz and 2.4dBi in 704-716 MHz. This transmitter is approved for use in mobile RF exposure use condition with the antenna(s) installed providing a separation distance of at least 20 cm from all persons. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 09/01/2015 Application Dated: 09/01/2015 |
| Kyocera Corporation |
| 2-1-1 Kagahara, Tsuzuki-ku |
| Yokohama-shi, Kanagawa, 224-8502 Japan |
| Attention: Yoshikazu Yamamoto , Manager, Quality Assurance Department |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | JOYKA36 |
| Name of Grantee: | Kyocera Corporation |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.221 | 2.5 PM | 4M17F9W | |
| 22H | 829.0 - 844.0 | 0.166 | 2.5 PM | 9M00G7W | |
| 22H | 829.0 - 844.0 | 0.132 | 2.5 PM | 8M99D7W | |
| 22H | 826.5 - 846.5 | 0.168 | 2.5 PM | 4M53G7W | |
| 22H | 826.5 - 846.5 | 0.135 | 2.5 PM | 4M53D7W | |
| 27 | 704.0 - 711.0 | 0.189 | 2.5 PM | 9M01G7W | |
| 27 | 704.0 - 711.0 | 0.15 | 2.5 PM | 9M01D7W | |
| 27 | 701.5 - 713.5 | 0.194 | 2.5 PM | 4M52G7W | |
| 27 | 701.5 - 713.5 | 0.152 | 2.5 PM | 4M53D7W | |
| 24E | 1852.4 - 1907.6 | 0.258 | 2.5 PM | 4M16F9W | |
| 24E | 1860.0 - 1900.0 | 0.2 | 2.5 PM | 18M0G7W | |
| 24E | 1860.0 - 1900.0 | 0.155 | 2.5 PM | 18M0D7W | |
| 24E | 1851.5 - 1908.5 | 0.204 | 2.5 PM | 2M71G7W | |
| 24E | 1851.5 - 1908.5 | 0.162 | 2.5 PM | 2M72D7W | |
| 27 | 1720.0 - 1745.0 | 0.188 | 2.5 PM | 17M9G7W | |
| 27 | 1720.0 - 1745.0 | 0.148 | 2.5 PM | 17M9D7W | |
| 27 | 1712.5 - 1752.5 | 0.188 | 2.5 PM | 4M52G7W | |
| 27 | 1712.5 - 1752.5 | 0.15 | 2.5 PM | 4M52D7W |
| Modular approval. Power output is conducted. Values listed for LTE operations are for the highest power and the widest bandwidth for each band and modulation. This device supports LTE bandwidths of: 1.4MHz, 3MHz, 5MHz, 10MHz in LTE Band 5 and LTE Band 12; 1.4MHz, 3MHz, 5MHz, 10MHz, 15MHz and 20MHz in LTE Band 2 and LTE Band 4. The maximum antenna gain is 4.9dBi in 1850-1910 MHz, 3.8dBi in 824-849 MHz, 4.0dBi in 1710-1755 MHz and 2.4dBi in 699-716 MHz. This transmitter is approved for use in mobile RF exposure use condition with the antenna(s) installed providing a separation distance of at least 20 cm from all persons. |
EAS Grant - Application +IbqPQsQ4Q9tPCX1+jNpXA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Kyocera Corporation 2-1-1 Kagahara, Tsuzuki-ku Yokohama-shi, Kanagawa, 224-8502 Japan |
Date of Grant: 09/01/2015 Application Dated: 09/01/2015 |
| Attention: Yoshikazu Yamamoto , Manager, Quality Assurance Department |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | JOYKA36 |
| Name of Grantee: | Kyocera Corporation |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.221 | 2.5 PM | 4M17F9W | |
| 22H | 829.0 - 844.0 | 0.166 | 2.5 PM | 9M00G7W | |
| 22H | 829.0 - 844.0 | 0.132 | 2.5 PM | 8M99D7W | |
| 22H | 826.5 - 846.5 | 0.168 | 2.5 PM | 4M53G7W | |
| 22H | 826.5 - 846.5 | 0.135 | 2.5 PM | 4M53D7W | |
| 27 | 704.0 - 711.0 | 0.189 | 2.5 PM | 9M01G7W | |
| 27 | 704.0 - 711.0 | 0.15 | 2.5 PM | 9M01D7W | |
| 27 | 701.5 - 713.5 | 0.194 | 2.5 PM | 4M52G7W | |
| 27 | 701.5 - 713.5 | 0.152 | 2.5 PM | 4M53D7W | |
| 24E | 1852.4 - 1907.6 | 0.258 | 2.5 PM | 4M16F9W | |
| 24E | 1860.0 - 1900.0 | 0.2 | 2.5 PM | 18M0G7W | |
| 24E | 1860.0 - 1900.0 | 0.155 | 2.5 PM | 18M0D7W | |
| 24E | 1851.5 - 1908.5 | 0.204 | 2.5 PM | 2M71G7W | |
| 24E | 1851.5 - 1908.5 | 0.162 | 2.5 PM | 2M72D7W | |
| 27 | 1720.0 - 1745.0 | 0.188 | 2.5 PM | 17M9G7W | |
| 27 | 1720.0 - 1745.0 | 0.148 | 2.5 PM | 17M9D7W | |
| 27 | 1712.5 - 1752.5 | 0.188 | 2.5 PM | 4M52G7W | |
| 27 | 1712.5 - 1752.5 | 0.15 | 2.5 PM | 4M52D7W |
| Modular approval. Power output is conducted. Values listed for LTE operations are for the highest power and the widest bandwidth for each band and modulation. This device supports LTE bandwidths of: 1.4MHz, 3MHz, 5MHz, 10MHz in LTE Band 5 and LTE Band 12; 1.4MHz, 3MHz, 5MHz, 10MHz, 15MHz and 20MHz in LTE Band 2 and LTE Band 4. The maximum antenna gain is 4.9dBi in 1850-1910 MHz, 3.8dBi in 824-849 MHz, 4.0dBi in 1710-1755 MHz and 2.4dBi in 699-716 MHz. This transmitter is approved for use in mobile RF exposure use condition with the antenna(s) installed providing a separation distance of at least 20 cm from all persons. |
| Mail To: |
