KC01 Mobile phone Test Setup Photos - FCC ID JOYKC-01

FCC ID JOYKC-01

SAR test setup photos

Mobile phone

by Kyocera Corporation

Document preview loads when visible.

Document Details

FCC IDJOYKC-01
Document ID2430971
Document TypeTest Setup Photos
DescriptionSAR test setup photos
Document TitleC-14093_Test Photo_KC-01_FCC_SAR
ApplicantKyocera Corporation
Equipment ClassMobile phone
Product CodeKC01
Application IDskQynLNXeC26P1/KVpYCdg==
Application PurposeOriginal Equipment
Application Date2014-10-29
Frequency Range1850.2-1909.8 MHz
FRN0021250543
Test FirmTUV SUD Zacta Ltd.
Certified ByYoshikazu Yamamoto
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date04/27/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-10-29
Available2015-04-27
Created2014-10-17
Modified2014-10-17
Pages12
File TypeAdobe Acrobat PDF
File Size1206902
File SHA-256ec27c73af1755ca2e6408a67650243d72c7ba5146b6b1ae4071d6440b170d4c5
PDF Metadata Authorkanno-ch
PDF Metadata ProducerJUST PDF 3 kanno-ch
FCC.gov SourcesFCC.gov 2430971, FCC.gov 2430945
