0073 HVAC controller Block Diagram - FCC ID JPZ0073
FCC ID JPZ0073
block diagram
HVAC controller
Document preview loads when visible.
Document Details
| FCC ID | JPZ0073 |
|---|---|
| Document ID | 1407146 |
| Document Type | Block Diagram |
| Description | block diagram |
| Document Title | Untitled |
| Applicant | Lutron Electronics Company Inc |
| Equipment Class | HVAC controller |
| Product Code | 0073 |
| Application ID | 2/5Cwb+mbEvjTRRuEzVkJg== |
| Application Purpose | Original Equipment |
| Application Date | 2011-01-20 |
| Frequency Range | 431-437 MHz |
| FRN | 0006220891 |
| Test Firm | UL LLC |
| Certified By | Robert Spehalski Senior Engineering Technician |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2011-01-20 |
| Available | 2011-01-20 |
| Created | 2010-11-19 |
| Modified | 2010-11-19 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 146823 |
| File SHA-256 | e0ddd60d7a11973bc7d58a7dfd778bf758986457189cbbdac531d5bdb3a2e5e6 |
| PDF Metadata Author | None |
| PDF Metadata Creator | Acrobat Editor 8.0 |
| PDF Metadata Producer | Adobe Acrobat 8.1.6 |
| FCC.gov Sources | FCC.gov 1407146 |
