0074 RF Theromstat Block Diagram - FCC ID JPZ0074
FCC ID JPZ0074
block diagram
RF Theromstat
Document preview loads when visible.
Document Details
| FCC ID | JPZ0074 |
|---|---|
| Document ID | 1407183 |
| Document Type | Block Diagram |
| Description | block diagram |
| Document Title | Microsoft PowerPoint - JPZ0074 block_diagram.ppt [Compatibility Mode] |
| Applicant | Lutron Electronics Company Inc |
| Equipment Class | RF Theromstat |
| Product Code | 0074 |
| Application ID | 8axJzuZoGJWXcI7xUUWCrA== |
| Application Purpose | Original Equipment |
| Application Date | 2011-01-20 |
| Frequency Range | 431-437 MHz |
| FRN | 0006220891 |
| Test Firm | UL LLC |
| Certified By | Robert Spehalski Senior Engineering Technician |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2011-01-20 |
| Available | 2011-01-20 |
| Created | 2011-01-03 |
| Modified | 2011-01-03 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 163263 |
| File SHA-256 | 13f61ea5890f8dadd492091bd0c828a587e330b2aa3616e1275efaeb59786086 |
| PDF Metadata Author | 10675 |
| PDF Metadata Creator | PScript5.dll Version 5.2.2 |
| PDF Metadata Producer | Acrobat Distiller 9.3.3 (Windows) |
| FCC.gov Sources | FCC.gov 1407183 |
