B78 RF Laser Basestation Teardown Internal Photos - FCC ID JWSB78

FCC ID JWSB78

Internal Photos

RF Laser Basestation

by Worthdata Inc

Document preview loads when visible.

Document Details

FCC IDJWSB78
Document ID624236
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleFull page fax print
ApplicantWorthdata Inc
Equipment ClassRF Laser Basestation
Product CodeB78
Application IDbrYevdT4nQJiFo+94KkmxQ==
Application PurposeOriginal Equipment
Application Date2006-01-26
Frequency Range903-927 MHz
FRN0009510215
Test FirmCompliance Certification Services Inc
Certified ByThu Chan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2006-01-30
Available2006-01-26
Created2005-12-20
Modified2005-12-20
Pages6
File TypeAdobe Acrobat PDF
File Size2351226
File SHA-25632bcd71f4f852a1f80630735f890f38adc12886f15adfbc4ae2e61fa0a04bc9b
PDF Metadata Authorchoque
PDF Metadata ProducerAcrobat Distiller 5.0.5 (Windows) choque
FCC.gov SourcesFCC.gov 624236
