7000 ActiveLink Module External Photos - FCC ID K3N7000

FCC ID K3N7000

Front

ActiveLink Module

by Glenayre Electronics Inc.

Front

Document Details

FCC IDK3N7000
Document ID105269
Document TypeExternal Photos
DescriptionFront
ApplicantGlenayre Electronics Inc.
Equipment ClassActiveLink Module
Product Code7000
Application IDo9YEYd41LjM+eWOc+dnxmA==
Application PurposeOriginal Equipment
Application Date2000-08-09
Frequency Range896-902 MHz
FRN9999999999
Test FirmCKC Laboratories, Inc.
Certified ByTracy Phillips Documentation Control Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2000-06-16
Available2000-08-09
Pages0
File TypeJPEG Image
File Size145014
File SHA-256552248ae746f17f1ad2c5fe704b8cb7cd5cfbcd13859f67fcdec349cd6468d88
FCC.gov SourcesFCC.gov 105269
