10654820 UHF HANDHELD TRANSCEIVER Label Diagram - FCC ID K6610654820

FCC ID K6610654820

ID DRAWING

UHF HANDHELD TRANSCEIVER

by Yaesu Musen Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDK6610654820
Document ID856235
Document TypeID Label/Location Info
DescriptionID DRAWING
Document TitleK6610654820_511B-10654820_IDDrawing.cdr
ApplicantYaesu Musen Co., Ltd.
Equipment ClassUHF HANDHELD TRANSCEIVER
Product Code10654820
Application IDzMWFp0lW7weqRxxIvqDhsQ==
Application PurposeOriginal Equipment
Application Date2007-10-31
Frequency Range380-470 MHz
FRN0013655220
Test FirmTimco Engineering, Inc.
Certified ByMOTO KURIHARA GROUP LEADER OF THE ENGINEERING DIVISION
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2007-10-18
Available2007-10-31
Created2007-09-03
Modified2007-09-03
Pages1
File TypeAdobe Acrobat PDF
File Size791202
File SHA-256e9c3a389efbc6364fbc327e20b7e4cef2b3564ed88f6eb0bc37ef72221aec29d
PDF Metadata AuthorNone
PDF Metadata CreatorCorelDRAW 12.0
PDF Metadata ProducerCorel PDF Engine Version 1.0.0.458
FCC.gov SourcesFCC.gov 856235
